Technical data

LOCKING RINGS

1. Examine all the locking rings carefully before fitting.

Always replace the gudgeon pin circlips after every use. Re-

place distorted locking rings. On fitting a locking ring (1),

ensure that the sharp edge (2) is on the opposite side to the

force to be applied to it.

See the figure on the side, (4) Axle.

SPECIAL TOOLS

1. The following special tools are needed for assembly and

for complete and exact adjustments. Only use the proper

special tools; thereby avoiding damage caused by the use of

unsuitable tools or improvised techniques.

OC G GS

SPECIAL TOOLS

STORES CODE

IMAGEDESCRIPTION

Air heater

Digital multimeter

Single battery charger

Multiple battery charger

15 mm pliers

020151Y

020331Y

020333Y

020334Y

001467Y014
