Technical data

23
Cylinder
Cylinder
Piston
Piston
NAME
PLAY
72+0,018±0,010
72+0,018±0,010
71,967±0,014
71,967±0,014
INITIAL
A
B
C
D
CYLINDER
71,990 ÷ 71,997
71,997 ÷ 72,004
72,004 ÷ 72,011
72,011 ÷ 72,018
PISTON
71,953 ÷ 71,960
71,960 ÷ 71,967
71,967 ÷ 71,974
71,974 ÷ 71,981
Pi
s
t
on
P
i
sto
n
Cylinde
r
C
yli
n
d
e
r
PLAY ON FITTING
0,030-0,044
0,030-0,044
0,030-0,044
0,030-0,044
COUPLING CATEGORIES ENGINE 250
UPRATING TABLE ENGINE 125
PISTON RINGS
NAME
DESCRIPTION DIMENSIONS
57 x 1
57 x 1
57 x 2,5
INITIALS
A
A
A
0,15 ÷ 0,30
0,10 ÷ 0,30
0,15 ÷ 0,35
QUANTITY
Compression lining
Scraper ring lining
Scraper ring lining
