Technical data

22
OVERHAUL DATA
ASSEMBLY CLEARANCES
CYLINDER - PISTON ASSY
Cylinder
Cylinder
Piston
Piston
Cylinder first uprat.
Cylinder first uprat.
Piston first uprat.
Piston first uprat.
Cylinder second uprat.
Cylinder second uprat.
Piston second uprat.
Piston second uprat.
Cylinder third uprat.
Cylinder third uprat.
Piston third uprat.
Piston third uprat.
NAME
PLAY
57+0,025±0,003
57+0,025±0,003
56,959±0,014
56,959±0,014
57,2+0,025 ± 0,003
57,2+0,025 ± 0,003
57,159±0,014
57,159±0,014
57,4+0,025 ± 0,003
57,4+0,025 ± 0,003
57,359±0,014
57,359±0,014
57,6+0,025 ± 0,003
57,6+0,025 ± 0,003
57,559±0,014
57,559±0,014
INITIALS
A
B
C
D
A1
B1
C1
D1
A2
B2
C2
D2
A2
B3
3C
D3
CYLINDER
56,997 ÷ 57,004
57,004 ÷ 57,011
57,011 ÷ 57,018
57,018 ÷ 57,025
57,197 ÷ 57,204
57,204 ÷ 57,211
57,211 ÷ 57,218
57,218 ÷ 57,225
57,397 ÷ 57,404
57,404 ÷ 57,411
57,411 ÷ 57,418
57,418 ÷ 57,425
57,597 ÷ 57,604
57,604 ÷ 57,611
57,611 ÷ 57,618
57,618 ÷ 57,625
PISTON
56,945 ÷ 56,952
56,952 ÷ 56,959
56,959 ÷ 56,966
56,966 ÷ 56,973
57,145 ÷ 57,152
57,152 ÷ 57,159
57,159 ÷ 57,166
57,166 ÷ 57,173
57,345 ÷ 57,352
57,352 ÷ 57,359
57,411 ÷ 57,418
57,366 ÷ 57,373
57,545 ÷ 57,552
57,552 ÷ 57,559
57,559 ÷ 57,566
57,566 ÷ 57,573
PLAY ON
FITTING
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
0,045-0,059
CATEGORIES COUPLING 125
