Technical data

Engine crankcase coupling screws

Starter motor screws

Crankcase timing cover screws

NAME

TORQUE IN Nm

ENGINE CRANKCASE AND SHAFT

4 ÷ 6

11 ÷ 13

3,5 ÷ 4,5

Engine crankcase inside head screws

(transmission side half shaft)

Water pump impeller cover

Water pump impeller drive joint screw

Thermostat cover screws

NAME

TORQUE IN Nm

COOLING

3 ÷ 4

(°) Apply threadlocking LOCTITE médium, type 242.

(*) Tighten the two screws after tightening the rear wheel spindie nut with the prescribed torque.

(A)Tighten the nuts ¡n two phases, following a crosswise pattern.

(1) Lubrícate nuts with engine oil before fitting.
