Remove the special punch from the press piston and support
the flywheel cover from the impeller side with it.
Put the new oil seal on the special punch while being careful
to position the seal lip starting from the side of the handle.
Install the oil seal on the flywheel cover all the way to the
depth determined by the punch.
Specific tooling
020628Y Water pump overhaul kit - quasar 250
Fit the punch with the template of the entrainment joint to
the press punch.
Position the entrainment joint on the shaft and using the
press, drive it to the depth determined by the punch.
Specific tooling
020628Y Water pump overhaul kit - quasar 250
