Position the flywheel cover on the press using the support
base for the bearings that is part of the special tool. Install
the special punch with the impeller’s template on the press
piston.
Specific tooling
020628Y Water pump overhaul kit - quasar 250
Manually insert the pump shaft in the relative bearings.
While keeping the bearings in contact with the support base,
line up the shaft with the press piston and proceed with the
driving. The driving depth is determined by the beat of the
punch when it is in contact with the flywheel cover.
N.B.
SO AS TO NOT DAMAGE THE FLYWHEEL COVER DURING
THE DRIVING OPERATION, SLIGHTLY TURN IT BY HAND IN
ORDER TO BETTER PERCEIVE THE MOMENT OF CONTACT
WITH THE PUNCH.
Specific tooling
020628Y Water pump overhaul kit - quasar 250
