Remove the ceramic seal from the pump shaft. Using a
screwdriver, remove the ceramic ring and sealing gasket
from the flywheel cover.
N.B.
IN THE EVENT YOU PLAN TO REUSE THE MECHANICAL
SEAL, PAY ATTENTION DURING THE DISASSEMBLY STAGES
IN ORDER TO NOT CHIP THE CERAMIC RING.
- Remove the joint from the seat inside the seal ring.
- Position the flywheel cover in the press while sustaining it
using the surface to be used for coupling with the engine
case.
ATENCIÓN
CHECK THE POSITIONING OF THE CENTRING DOWELS.
PROPERLY PROTECT THE COUPLING SURFACE.
Centre the cover until it permits insertion of the pin and then
eject the seal ring and the two ball bearings.
Specific tooling
020628Y Water pump overhaul kit - quasar 250
