Technical data

210
N.B.
PERFECTLY CENTRE THE PUNCH ON THE IMPELLER. MOVE
THE SHAFT AND CHECK THAT THE FLYWHEEL COVER TUR-
NS IN PLANE. FAILURE TO OBSERVE THIS REGULATION
CAN DAMAGE THE DRIVE.
N.B.
DO NOT LUBRICATE THE 0-RING. FAILURE TO OBSERVE
THIS RULE CAUSES A DEFORMATION OF THE RING.
Specific tooling
020440Y Water pump overhaul tool
Locking torques (N*m)
Water pump impeller cover 3 ÷ 4
ENGINE 250
- Remove the complete flywheel cover
- Remove the stator
- Remove the pump cover by loosening the 3 fixing screws
- Remove the sealing gasket
