DISMANTLING FRONT SUSPENSION
ATTENTION
TO CARRY OUT THE PROCESS OF DISMANTLING THE FOR-
KS WITHOUT REMOVING THEM FROM THE BOTTOM PLATE.
TO DO SO, HOLD THE FORKS IN A BENCH VICE BY THE
STEERING COLUMN, THEREBY PREVENTING THEM FROM
BEING SCRATCHED.
- Extract the top closing bolt.
- Remove the top bolt.
ATENCIÓN
THE BOTTOM BAR OF THE FORKS WILL COME FREE. HOLD
IT TO PREVENT IT FROM FALLING.
Have ready a suitable sized container in which to drain off
the hydraulic fluid from each bar (pump the fork stem assem-
bly in order to ensure it is completely drained).
DISMANTLING FRONT SUSPENSION
