Remove the spray nozzle.
- Remove the minimum flow screw with the O-Ring, washer and
spring.
- Remove the 2 fixing screws, the cover, the spring and the cut-
off device membrane.
CAUTION
DO NOT REMOVE THE COMPONENTS FIXED INTO THE CAR-
BURETTOR BODY, SUCH AS: FUEL FEEDING DUCT, PIN SEAT,
STARTER NOZZLE, PICKUP NOZZLE AND PIT CAP, MINIMUM
AND MAXIMUM AIR CALIBRATOR, THROTTLE VALVE CONTROL
SHAFT. DO NOT REMOVE THE SCREWS FIXING THE THROTTLE
TO THE SHAFT. THE FIXING SCREWS ARE CAULKED AFTER AS-
SEMBLY AND THEIR REMOVAL DAMAGES THE SHAFT.
