FUEL SUPPLY
REMOVING THE CARBURETTOR
KEHIN
- To disconnect the carburettor from the engine, it is neces-
sary to move the air filter and remove the gas control trans-
mission, the automatic starter connection, the clamps fixing
the carburettor to the filter box and to the intake manifold,
the pipe feeding air to the membrane, and the intake uni-
on.
- Extract the carburettor and turn it to remove the screw with
the water union and relevant pipes.
N.B.
THIS OPERATION IS REQUIRED TO PREVENT EMPTYING THE
COOLING SYSTEM.
Remove the guard, the bracket and the starter by releasing
the screw shown in the figure.
Remove the 2 screws and the starter support with the gasket.
