- Remove the two screws shown in the figure.
- Extract the motor from its seat.
REMOVING THE FLYWHEEL MAGNETO
- Hold the flywheel using the adjustable spanner.
- Remove the lock-nut.
- Extract the flywheel.
CAUTION
USING A DIFFERENT WRENCH COULD DAMAGE THE STA-
TOR COILS.
Specific tooling
020565Y Compass flywheel stop spanner
008564Y Flywheel extractor
- Remove the water pump shaft and driving shaft keying
spring.
REMOVING THE FLYWHEEL MAGNETO
