User guide

5
DAB+P has an additional AUX-input (3.5mm) into which other external devices can
be connected. In order to use it, just connect the device and pause the playback
on the ‘Dension DAP+P’ App.
POSITIONING THE DAB ANTENNA
The DAB reception and performance depends on many factors, both in the vehicle
and other external conditions. Before you start the antenna installation and/or the
product testing, please make sure that you have a good DAB coverage and
reception.
Important notes:
• If your vehicle comes with metalized windscreen (e.g. windscreen heating) an
external antenna is required
• The DAB module supports both amplifi ed and non-amplifi ed aerials. For
amplifi ed antennas 12V power is provided by the DAB+P receiver via the 2 pin
molex connector
Read the manual of the antenna used carefully and follow the instructions in order
to fi nd the right place for installation. Always test (read next chapter) the DAB
functions before fi nalizing the installation.
