ENGLISH Thank you for choosing the DENON AVR-1907 AV Surround Receiver. This remarkable component has been engineered to provide superb surround sound listening with home theater sources such as DVD, as well as providing outstanding high fidelity reproduction of your favorite music sources. As this product is provided with an immense array of features, we recommend that before you begin hookup and operation that you review the contents of this manual before proceeding.
ENGLISH Advanced Setup – Part 1 System setup items and default values ····························43 ~ 45 Navigating through the System Setup Menu ···························46 About the on screen display and front display ·························47 Audio Input Setup Setting the Digital In Assignment ················································47 Setting the EXT IN Subwoofer Level ···········································48 Setting the iPod Assignment ·················································
ENGLISH Getting Started Getting Started Cautions on installation About the remote control unit Note: For heat dispersal, do not install this unit in a confined space such as a bookcase or similar enclosure. In addition to controlling the AVR-1907, the attached remote control unit (RC-1046) can also be used to control the following products: q DENON component products w Component products other than DENON: • Set using the preset memory function ( page 58).
ENGLISH Getting Started Getting Started !6 Cursor buttons (D, H) ·······························(11) !7 MASTER VOLUME control knob··············(21) !8 TUNING buttons (•, ª) ·····························(33) !9 STATUS button ··········································(22) @0 DIMMER button ·········································(22) @1 VIDEO SELECT button ······························(36) @2 Display Part names and functions For details on the functions of these parts, refer to the pages given in parenth
ENGLISH Getting Started Getting Started Rear panel Remote control unit !5 !4 !3 !2 !1 !0 o i [ Front ] u y Remote control signal transmitter ························(3) Indicator ··························(58) Power buttons················(10) Tuner system/System buttons······················(33, 59) Function buttons············(21) q w e r t System buttons ·····(59 ~ 61) q ZONE2 terminals ·······································(19) o COMPONENT VIDEO terminals··················(9) w EXT.
ENGLISH Getting Started Getting Started [ Rear ] ZONE2 buttons···············(41) MAIN buttons ·················(41) Function / Number buttons ····························(21) SURROUND MODE buttons ····························(23) Tuner system/System buttons······················(33, 61) TEST TONE/DISPLAY button························(57, 59) Cursor buttons (D, H, F, G) ····················(11) SYSTEM SETUP/SETUP button························(11, 59) SURROUND PARAMETER/ AUDIO button···········(21
ENGLISH Easy Setup Procedure Speaker layout [Basic layout] Easy Setup Procedure Example of basic layout with eight speakers and a monitor. • This section contains the basic steps necessary to configure the AVR-1907 according to your listening room environment and the source equipment and loudspeakers you are using. • To set the sound field manually ( page 54 ~ 57). Subwoofer Center speaker Surround back speaker Easy to setup flow Placing the speakers. Auto setup flow Connecting the speakers.
ENGLISH Easy Setup Procedure Easy Setup Procedure ¢ Connections Speaker connections Connect the speaker terminals with the speakers making sure that like polarities are matched (< with <, > with >). NOTE: When making connections, take care that none of the individual conductors of the speaker cable come in contact with adjacent terminals, with other speaker cable conductors, or with the rear panel and screws. NEVER touch the speaker terminals when the power is on.
ENGLISH Easy Setup Procedure Easy Setup Procedure • For best picture quality (especially with progressive DVD and other high definition sources), choose the component video connection to your monitor. S-Video and composite video outputs are also provided if your monitor does not have component video inputs. Connecting a DVD player and monitor • To connect the video output from the DVD player to the AVR-1907, you only need to choose one connection type.
ENGLISH Easy Setup Procedure Easy Setup Procedure w Before performing the Auto Setup procedure Auto Setup SYSTEM SETUP The AVR-1907’s auto setup use the attached microphone to measure the acoustic properties in the room and automatically make the optimum settings. • To make the sound field settings manually ( D H F G, ENTER page 54 ~ 57). q Connecting a microphone the attached setup microphone to . 1 Turn on your subwoofer.
ENGLISH Easy Setup Procedure Easy Setup Procedure e Perform the Auto Setup procedure 1 Press SYSTEM SETUP. 2 Press D H to select “Auto Setup”, then press ENTER. 3 Press D H to select “Auto Setup”, then press ENTER. The message “Connect Microphone” is displayed if no microphone is connected. If so, connect the auto setup microphone. Surround Back: Assign to use as surround back speaker. ZONE2: Assign to use as “ZONE2” speakers.
ENGLISH Easy Setup Procedure Easy Setup Procedure u Checking and storing the measurement results 1 Press D H to select an item, then press ENTER. The measurement results of each item can be checked here. 2 After checking, press ENTER, then press D H to set. Error messages • These error screens may be displayed when performing Auto Setup measurement and the automatic measurements can not be completed because of the speaker arrangement, measurement environment, or other factors.
ENGLISH Easy Setup Procedure Check the parameter Connecting Other Sources • The results of the measured items can be checked. • This item is displayed, after the measurement result of the “Auto Setup” is decided. 1 Press D H to select “Parameter Check”, then press ENTER. 2 Press D H to select the item, then press ENTER. 3 Press ENTER. Cable indications The hookup diagrams on the subsequent pages assume the use of the following optional connection cables (not supplied).
ENGLISH Connecting Other Sources Connecting Other Sources The video conversion function On screen display signals With the AVR-1907, the Video signal and the S-Video signal which were inputted are mutually converted. And also the Video signal and the S-Video signal which were inputted are converted into a higher quality. The flow of the video signals.
ENGLISH Connecting Other Sources Connecting Other Sources Connecting a TV/DBS tuner Connecting the external inputs (EXT. IN) terminals • These terminals are for inputting multi-channel audio signals from an outboard decoder, or a component with a different type of multi-channel decoder, such as a DVD-Audio player, or a multi-channel Super Audio CD player, or other future multi-channel sound format decoder. • The video signal connection is the same as that for a DVD player ( page 9).
ENGLISH Connecting Other Sources Connecting Other Sources Connecting a CD player Connecting a VCR To connect the digital audio output from the CD player, you can choose from either the coaxial or optical connections. If you choose to use the optical connection, it needs to be assigned. For more information about Digital Input Assignment ( page 47). • For best picture quality choose the component video connection to your VCR. S-Video and composite video outputs are also provided.
ENGLISH Connecting Other Sources Connecting Other Sources Connecting a CD recorder or MD recorder Connecting the antenna terminals An F-type FM antenna cable plug can be connected directly. • If you wish to perform analog dubbing from a digital source, such as a CD or MD recorder to an analog recorder such as a tape deck, you will need to connect the analog inputs and outputs as shown below, in addition to the digital audio connections.
ENGLISH Connecting Other Sources NOTE: • Do not connect two FM antennas simultaneously. • Even if an external AM antenna is used, do not disconnect the AM loop antenna. • Make sure the AM loop antenna lead terminals do not touch metal parts of the panel.
ENGLISH Connecting Other Sources Connecting Other Sources Connecting the MULTI ZONE terminals ZONE2 speaker out connections For instructions on operations using the MULTI ZONE functions ( • When the power amplifier is assigned to the ZONE2 output channel at “Power Amp Assignment” in the “System Setup” menu, the surround back speaker terminals can be used as the ZONE2 speaker out terminals ( page 53).
ENGLISH Connecting Other Sources Connecting Other Sources Connecting the PRE OUT terminals Connecting the power supply cord • Use these terminals if you wish to connect external power amplifier(s) to increase the power of the front, center, surround and surround back sound channels, or for connection to powered loudspeakers. • When using only one surround back speaker, connect it to the left channel.
ENGLISH INPUT MODE STATUS VOLUME FUNCTION DIMMER Basic Operation Playing the input source 1 4 Use VOLUME to adjust the volume. • The volume level is displayed on the master volume level display. Use FUNCTION to select the input source you want to play. To select the input source when ZONE2/REC SELECT is selected, press then operate . SURROUND PARAMETER 2 Press INPUT MODE. • The input mode indicator lights. AUTO PCM EXT.
ENGLISH Basic Operation Basic Operation Turning the sound off temporarily (MUTING) Checking the currently playing program source, etc. Press [MUTING]. You can adjust the muting level ( Using the surround modes Types of surround modes and their features page 53). ¢ On screen display The AVR-1907 is equipped with many surround modes. We recommend using the surround modes as described below in order to achieve the maximum effect for the specific signal source. Press [ON SCREEN].
ENGLISH Basic Operation Basic Operation Sources recorded in stereo Sources recorded in monaural DIRECT / STEREO • Effective for achieving pure playback. • If there is no need for tone control or distribution of the low frequencies in function of the speaker configuration, select the DIRECT mode to achieve the best sound quality. Selecting the play mode (DIRECT/STEREO) DOLBY PRO LOGIC IIx* ( page 25) • Developed by Dolby Laboratories, this surround mode provides 7.
ENGLISH Basic Operation Basic Operation Selecting the Dolby Digital and DTS Surround mode (only with digital input) an input source for which digital (COAXIAL or 1 Select OPTICAL) is set ( page 47). 2 Press INPUT MODE to select “AUTO”. [STANDARD] to select “STANDARD (Dolby/DTS 3 Press Surround)”. 4 Play a program source with the •“ ” or “ , mark. ” lights, depending on the source. 5 Press SURROUND PARAMETER. 6 Press D H to select the item, then press F G to set. CINEMA EQ.
ENGLISH Basic Operation Basic Operation F G, ENTER Selecting the Dolby Pro Logic IIx (Pro Logic II) mode When “MUSIC” mode is selected: It is possible to play analog input signals and digital input signals (2channels) in the surround mode. This mode is optimal for playing program sources recorded in Dolby Surround. 1 Press [STANDARD] to select “DOLBY PLIIx”. ENTER DHFG [ON SCREEN] NEURAL SURROUND 2 Play a program source. 3 Press SURROUND PARAMETER. 4 Press F G to select the play mode.
ENGLISH Basic Operation Basic Operation Selecting the DTS NEO:6 mode It is possible to play analog input signals and digital input signals (2channels) in the surround mode. 1 Press [STANDARD] to select “DTS NEO:6”. DOLBY PLIIx DTS NEO:6 NEURAL SURROUND 2 Play a program source. 3 Press SURROUND PARAMETER. 4 Press F G to select the play mode. CINEMA: This mode is optimum for playing movies.
ENGLISH Basic Operation Basic Operation Surround modes and parameters Signals and adjustability in the different modes Parameter (default values are shown in parentheses) Channel output Surround Mode STEREO EXT.
ENGLISH Basic Operation Basic Operation ¢ Differences in surround mode names depending on the input signals Button Input signals DTS Surround Mode STANDARD DTS SURROUND DTS ES DSCRT6.1 DTS ES MTRX6.
ENGLISH Basic Operation Basic Operation Button Input signals DTS Surround Mode DIRECT DIRECT DSP SIMULATION 5CH/7CH STEREO MONO MOVIE ROCK ARENA JAZZ CLUB VIDEO GAME MATRIX VIRTUAL STEREO STEREO Note *1 DOLBY DIGITAL DOLBY DOLBY DIGITAL EX DIGITAL (With no Flag) (5.1ch) DOLBY DIGITAL (2ch) DVD-Audio (multi ch) DVD-Audio (2ch) 176.
ENGLISH Basic Operation Basic Operation Using the DENON original surround modes The AVR-1907 is equipped with a high performance digital signal processor (DSP) that uses digital signal processing to recreate sound fields artificially. One of seven surround modes can be selected according to the program source and parameters can be further adjusted to achieve even more realistic sound fields.
ENGLISH Basic Operation Basic Operation Selecting the DSP surround simulation F G, SELECT/ENTER • Select “Default Yes” and press F to reset all the settings. ¢ To operate the surround mode and the surround parameters from the remote control unit 1 MONO MOVIE 5CH/7CH STEREO ROCK ARENA VIRTUAL , DH SURROUND PARAMETER [CH SELECT], ENTER DHFG ¢ Operating the surround mode and the surround parameters from the main unit’s panel Press [DSP SIMULATION].
ENGLISH Basic Operation Basic Operation Setting the tone control Adjust the bass and treble to suit your tastes. ¢ When you do not want to adjust the tone Set “Tone Defeat” to “ON” at step 3 in “Adjusting the tone”. ¢ Adjusting the tone 1 Press SURROUND PARAMETER. 2 Press D H to select “TONE DEFEAT”. Adjusting the speaker volume 1 Press [CH SELECT]. In the direct mode, “TONE” cannot be selected.
ENGLISH Basic Operation Basic Operation CHANNEL BAND TUNING Listening to the radio Auto tuning Check that the remote control unit is set to “AUDIO”. Auto preset memory This unit is equipped with a function for automatically searching for FM broadcast stations and storing them in the preset memory. to select “TUNER” or press 1 Use [TUNER]. 2 Press BAND to select “AM”, “FM” or “XM”.
ENGLISH Basic Operation Preset memory 1 Use the “Auto tuning” or “Manual tuning” operation to tune in the station to be preset in the memory. 2 Press [MEMORY]. Press SHIFT to select the desired memory block (A to 3 G). Basic Operation Recalling preset stations 1 Press SHIFT to select the memory block. 2 Press CHANNEL to select the desired preset channel. XM Satellite Radio AVR-1907 is the XM Ready receiver.
ENGLISH Basic Operation Basic Operation Checking the XM signal strength and Radio ID FG TUNING BAND STATUS Use to select “TUNER” or press to select “TUNER” or press 1 1 Use [TUNER]. [TUNER]. 2 Press BAND to select “XM”. 3 Press STATUS until “SIGNAL” is displayed. • The display changes as shown below according to the receiving condition. VIDEO SELECT DH [XM RADIO] Channel selection 2 Press BAND to select “XM”.
ENGLISH Advanced Operation Night mode The night mode can be set when playing Dolby Digital sources. The dialogues are easier to hear at night and when listening with the volume low. User mode function The AVR-1907 is equipped with a function for storing the selected input source, the auto surround mode and input mode in the memory and selecting these settings when you want to use them.
ENGLISH Advanced Operation Advanced Operation Playing the FUNCTION STATUS iPod® The music recorded on the iPod can be played when using a Control Dock for iPod (ASD-1R, sold separately). The iPod can be controlled using the buttons on the main unit and the remote control unit. iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
ENGLISH Advanced Operation Advanced Operation Listening to music D H] to select the music file, then press [ENTER] [D 1 Press G]. or [G F] to return to the music menu screen. Press [F 2 Press [ENTER] or [GG]. • Playback starts. Pause: Press [ENTER] during playback. Press again to resume. Manual search: D H] during playback. Press and hold in [D • D: Fast reverse • H: Fast forward Track search: D H] during playback.
ENGLISH Advanced Operation Multi zone music entertainment system • When the outputs of the ZONE2 OUT terminals are wired and connected to integrated amplifiers installed in other rooms, different sources can be played in rooms other than the MAIN ZONE in which this unit and the playback devices are installed. (Refer to ZONE2 of the diagram the right.) • ZONE2 speaker out and pre-out can be used when “ZONE2” is selected at “Power Amp Assignment” in the “System Setup” menu.
ENGLISH Advanced Operation Advanced Operation ¢ When using the SURR.BACK/ZONE2 amplifier as the ZONE2 • The SPEAKER OUT, LINE OUT and PRE OUT terminals can be used simultaneously in ZONE2. • To use the ZONE2, turn on ZONE2. • The output of the ZONE2 SPEAKER OUT terminals can be adjusted with [VOLUME] (ZONE2). [System configuration and connections example] Using this unit’s internal amplifier as the ZONE2. MAIN ZONE 5.
ENGLISH Advanced Operation Advanced Operation Outputting a program source to amplifier, etc., in the ZONE2 room (ZONE2 SELECT mode) Press to display the “ZONE2 1 SOURCE” on the display. RECOUT ZONE2 “ZONE2 SOURCE” displayed, turn 2 With to select the source you want to output appears on the display. • The “ -2” indicator and the indicator for the selected source light.
ENGLISH Advanced Operation Advanced Operation Recording (audio and/or video) 1 Press until “RECOUT” appears on the display. ZONE2 RECOUT Use to select the source to be recorded 2 (audio and/or video). • The “ ” indicator and the indicator for the selected source light. 3 Record (the audio or video signals). For operations, see the operating instructions of the device from which you are recording (audio or video signals).
ENGLISH Advanced Setup – Part 1 System setup items and default values 1. Auto Setup Items 1 Auto Setup 2. Speaker Setup Items 1 2 Automatically set the output component and properties for the various channels according to the combination of speakers to be actually used for surround playback. Subwoofer Setup Select the method of playback of the subwoofer for playing the low bass signals.
ENGLISH Advanced Setup – Part 1 Advanced Setup – Part 1 3. Audio Input Setup Items 1 Digital In Assignment EXT IN 2 Subwoofer Level Default settings This assigns the different input function for the digital input terminals. COAX 1 COAX 2 OPT 1 OPT 2 OPT 3 Input Function CD AUX DVD / VDP TV / DBS V.
ENGLISH Advanced Setup – Part 1 Advanced Setup – Part 1 5. Advanced Playback Items 2ch 1 Direct/Stereo 2 Make the 2-channel direct mode and stereo mode speaker settings. Auto Surround Mode Set whether or not to store the surround mode last played for the input signal. Power Amp Assign To suit your preference, a surround back channel’s power amplifier can be assigned to the front channel (“Front A” or “Front B”) for bi-amp playback, ZONE2. 6.
ENGLISH Advanced Setup – Part 1 Advanced Setup – Part 1 Use System Setup to customize a variety of settings to suit your listening environment. For the contents of a system menu and the initial setting of this unit ( page 44, 45). F G, ENTER Navigating through the System Setup Menu 1 Press SYSTEM SETUP. [ On screen display ] • The “System Setup” menu appears. SYSTEM SETUP DH 2 Press D H to select the item you want to set, then press ENTER.
ENGLISH Advanced Setup – Part 1 Advanced Setup – Part 1 About the on screen display and front display Audio Input Setup The AVR-1907 is equipped with an intuitive and easy-to-understand on screen display, and is equipped with an alphanumeric front panel display that can also be used to check and adjust settings. We recommend that you use the on screen display when you make system adjustments. Some representative front display and on screen display examples are shown below.
ENGLISH Advanced Setup – Part 1 Advanced Setup – Part 1 Setting the EXT IN Subwoofer Level Sets the playback level of the analog signal that was input to the EXT. IN subwoofer terminal. Setting the iPod Assignment Setting the Input Function Level It is possible to assign the Control Dock for iPod’s (ASD-1R, sold separately) audio and/or video signals to any input terminals on the AVR-1907 and play them. The playback level is corrected individually for the different input sources.
ENGLISH Advanced Setup – Part 1 Advanced Setup – Part 1 Setting the Function Rename The name of the input function that is displayed can be changed. 1 Press D H to select “Function Rename”, then press ENTER. D H to select the input function, then press F 2 Press G to set. Setting the Tuner Presets Preset channels that are not used often can be skipped. ¢ Auto Preset Memory Up to 56 FM stations can be preset automatically. 1 Press D H to select “Tuner Presets”, then press ENTER.
ENGLISH Advanced Setup – Part 1 ¢ Preset Name The preset channels can be given the names you want. (Except the XM channels.) 1 Press D H to select “Preset Name”, then press ENTER. D H to select the preset channel, then press F 2 Press G to set. F G to move the cursor ( 2 ) to the desired position, 3 Press then press D H to select the character. Advanced Setup – Part 1 1 3 2 4 Up to 8 characters can be input. The characters that can be input are shown below.
ENGLISH Advanced Setup – Part 1 Advanced Setup – Part 1 Video Setup Setting the Video Convert This sets whether or not to use the video conversion function. Setting the Audio Delay Adjust the time delay between the video and audio signals. Setting the Component In Assignment This assigns the different input sources for the component video input terminals. 1 Press D H to select “Video Setup”, then press ENTER. Press D H to select “Component In Assign”, then 2 press ENTER.
ENGLISH Advanced Setup – Part 1 Advanced Setup – Part 1 Setting the On Screen Display (OSD) Set whether or not to display the on screen display for indications other than the menu screens. D H to select “On Screen Display”, then press 1 Press ENTER. 2 Press D H to select the item, then press F G to set. Function/Mode Status: • ON, OFF: Select “ON” to display the on screen display when the input source is selected, “OFF” if you do not want to display it.
ENGLISH Advanced Setup – Part 1 Advanced Setup – Part 1 1 Option Setup Setting the Power Amplifier Assignment Setting the Volume Control 2 To suit your preference, a surround back channel’s power amplifier can be assigned to the front channel (“Front A” or “Front B”) for biamp playback, ZONE2. Power Amplifier Assignment Surround Back ZONE2 Bi-Amp SPEAKER OUT MAIN ZONE ZONE2 7.1ch system – 5.1ch system 2ch system 5.1ch system – This sets the volume level of output.
ENGLISH Advanced Setup – Part 1 Setting the Setup Lock Advanced Setup – Part 2 This sets whether or not to lock the system setup settings so that they cannot be changed. Speaker Setup 1 Press D H to select “Setup Lock”, then press ENTER. F G, ENTER 2 Press F to select “ON”, then press ENTER. 1 • If the “Auto Setup” procedure has already been performed, there is no need to make this setting. • Perform this setting if you wish to make the settings for your speaker systems manually.
ENGLISH Advanced Setup – Part 2 Advanced Setup – Part 2 A subwoofer with sufficient low frequency playback capability can better handle deep bass than most main and surround speakers, and the system’s overall performance will be greatly enhanced when “Small” is set for the main (front) and surround speakers. When “Front” is set to “Small”, “Subwoofer” is automatically set to “Yes”, and when “Subwoofer” is set to “No”, “Front” is automatically set to “Large”.
ENGLISH Advanced Setup – Part 2 1 Advanced Setup – Part 2 1 Setting the Channel Level 2 ..... ..... ..... ..... ..... ..... ..... ..... L1 L2 L3 L4 L5 L6 L7 L8 • The distance changes in units of 0.5 foot each time the button is pressed. Select the value closest to the measured distance. • Please note that the difference of distance for every speaker should be 20 ft or less.
ENGLISH Advanced Setup – Part 2 Advanced Setup – Part 2 ¢ Adjusting the test tone using the remote control unit Adjustment of the test tones using the remote control unit is only possible in the “Auto” mode and only valid in the STANDARD (Dolby/ DTS Surround) mode. The adjusted levels are automatically stored for the different surround modes.
ENGLISH Operating the remote control unit Operating DENON audio components [MODE SELECTOR 1] [MODE SELECTOR 2] 3 Press [ZONE2 OFF] and [MAIN ON] at the same time. • The indicator starts flashing. 1 Referring to the included list of preset codes, press 4 [NUMBER] to input the preset code (a 3-digit number) Set [MODE SELECTOR 2] to the position for the 2 component for the manufacturer of the component whose signals to be operated (CD, CD-R/MD or TAPE). Set [MODE SELECTOR 1] to “AUDIO”.
ENGLISH Operating the remote control unit Operating the remote control unit Operating a component stored in the preset memory 1 Set [MODE SELECTOR 1] to “AUDIO” or “VIDEO”. Set to the AUDIO side for the CD, TAPE or CD-R/MD position, and to the VIDEO side for the DVD/VDP, DBS/CABLE, VCR or TV position. 2 Set [MODE SELECTOR 2] to the component you want to operate.
ENGLISH Operating the remote control unit Operating the remote control unit ¢ Functions of buttons for the different devices [Front] Device operated CD player CD recorder MD recorder Tape deck DVD player Video disc player Video deck Cable TV TV (Monitor) VIDEO AUDIO MODE SELECTOR 1 Satellite tuner TV CD OFF – – – – Power off – – – – – ON / SOURCE – – – – Power on Power on /Standby Power on /Standby Power on /Standby Power on /Standby Power on /Standby SHIFT Preset ch
ENGLISH Operating the remote control unit Operating the remote control unit [Rear] Device operated CD player CD recorder MODE SELECTOR 1 MD recorder Tape deck DVD player Video disc player Video deck Satellite tuner Cable TV TV (Monitor) VIDEO AUDIO MODE SELECTOR 2 CD NUMBER (0 ~ 9, +10) – – – – Number input / Track selection Number input / Track selection – Channels Channels Channels TV/ VCR – – – – Input mode selection Input mode selection Input mode selection Input mod
ENGLISH Operating the remote control unit Operating the remote control unit Setting the punch through function [MODE SELECTOR 1] [MODE SELECTOR 2] “Punch Through” is a function allowing you to operate 1, 2, 6, 7, 8 and 9 on CD, TAPE, CD-R/MD, DVD/VDP or VCR components when in the DBS/CABLE or TV mode. By default, nothing is set. 1 Set [MODE SELECTOR 1] to “VIDEO”. Set [MODE SELECTOR 2] to the component to be 2 registered (DBS/CABLE or TV). 3 Press [MEMORY] and [INPUT MODE] at the same time.
ENGLISH Additional Information We recommend using two speakers. When using dipolar speakers in particular, be sure to use two speakers. Surround back speakers Sound position directly to the rear can be achieved easily by adding a surround back speaker to a 5.1-channel system.
ENGLISH Additional Information Surround Additional Information DTS NEO:6 surround DTS Digital Surround DTS Digital Surround is a digital surround format developed by Digital Theater Systems of the United States. The number of playback channels and the playing band is the same as for Dolby Digital (5.1-channels).
ENGLISH Troubleshooting Symptom Troubleshooting No sound is produced from subwoofer. If a problem should arise, first check the following. 1. Are the connections correct? 2. Have you operated the receiver according to the Operating Instructions? 3. Are the speakers and other components operating properly? If this unit is not operating properly, check the items listed in the table below. Should the problem persist, there may be a malfunction.
ENGLISH Troubleshooting Troubleshooting Symptom Cause Measures Page “OFF AIR” is displayed in the XM mode. • The selected channel is not currently • Select the another channel. broadcasting. 35 Receiving only XM channels 0 and 1. • The XM Tuner is not activated. 35 • Contact XM Radio.
ENGLISH ¢ List of preset codes DVD ASA 042 Go Video 047, 048 Minolta 013, 023 Denon 014, *[111] Asha 087 Goldstar 000, 006, 012, 062, 088 Mitsubishi 001, 003, 008, 013, 014, Aiwa 009 Audio Dynamic 005, 085 Gradiente 094 Hitachi 010 Audiovox 088 Grundig 042 JVC 006, 011 Beaumark 087 Harley Davidson 094 Motorola Konka 012, 013 Broksonic 086, 093 Harman Kardon 040, 062 Montgomery Ward Magnavox 005 Calix 088 Hi-Q 091 Mitsubishi 004 Candle 006, 087, 088, 089, 09
ENGLISH Radix 088 Technics 024, 049 Bell & Howell 045, 118 Fujitsu 004, 062 Randex 088 Teknika 009, 010, 022, 049, 088, Bradford 061 Funai 004, 062 RCA Realistic 094 Brockwood 003, 047 Futuretech 004 063, 064, 065, 073, 080, TMK 087, 092 Candle 003, 030, 031, 032, 038, GE 020, 036, 037, 040, 044, 082, 087 Toshiba 013, 017, 020, 041, 059, 007, 013, 019, 023, 058, 047, 049, 050, 122 058, 066, 088, 119, 120, 089, 098, 099, 117 Capehart 003 007, 087, 088 Celebrity 046 U
ENGLISH Magnavox 005, 010, 017, 030, 033, Philips 038, 050, 056, 071, 078, 005, 015, 017, 050, 051, Squareview 004 Eastern 015 056, 078, 087, 088, 089, Supre-Macy 032, 122 Garrard 011 131, 132, 147 Supreme 046 Gemini 030, 033, 034 110, 127, 131, 132, 145 Pioneer 124, 128, 142 Sylvania 005, 010, 017, 030, 078, General Instrument 030, 031, 032 015, 017, 071, 080 Portland 054 079, 085, 089, 101, 127, Hytex 006 Matsui 027 Price Club 095 131, 132, 145, 155 Jasco 011 Memorex
ENGLISH 062, 066 Magnavox 006, 015, 035 Optimus 007, 008 GE 048, 055, 056 Marantz 016, 028, 035 Panasonic 012 General Instruments 039, 040, 041 MCS 016, 024 Philips 002 Grundig 070, 071, 072, 073 Onkyo 025, 027 Pioneer 007, 008, 009 Hitachi 058, 059 Optimus 017, 020, 021, 022, 023 Sony 013, 014, 015 Hughes Network 063, 064, 065, 069 Philips 014, 032, 033, 035 Technics 012 JVC 057 Pioneer 006, 022, 030 Victor 004 Kathrein 074, 075, 076, 083 Sears 006 Wards 007 M
