AV Surround Control Center Brochure

16940707 A
Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
HDMI
Component
S-Video
Composite
Analog audio (Tuner included)
Analog EXT. Input
Analog L/R Input (XLR)
Digital OPTICAL
Digital COAXIAL
Digital COAXIAL BNC
Denon Link
Ethernet
Wi-Fi
USB
Dock control for iPod
6
6 (1:BNC)
8
8
11
7.1ch
1
5
4
2
1
1
1
2
1
H
DMI Monitor
C
omponent Main Monitor
Z
one 2 Monitor
S
-Video REC
M
onitor / Zone 2
C
omposite REC
M
onitor / Zone 2 / Zone 3
A
nalog audio REC
Z
one 2 / Zone 3
A
nalog Preout (RCA)
(
XLR)
D
igital OPTICAL REC
D
igital OPTICAL Zone 2
Digital OPTICAL REC / Zone 4
2
2(1:BNC)
1
3
1/1
3
1/1/1
3
1/1
9.3 ch
9.3 ch
2
1
1
I
N
OUT
Input / Output terminals
Specifications
General
Power supply AC 120 V, 60 Hz
Power consumption 2 A
(Standby : 0.3W)
D
imensions (WxHxD) 434 x 214 x 488 mm
17-2/16” x 8-7/16” x 19-7/32”
W
eight 26.8 kg, 59.1 lbs
*Design and specifications are subject to change without notice.
