User's Manual
Table Of Contents
Turbo CPU Board for UMAC Turbo & Turbo Stack
22 Accessories
UMAC Backplane-Mountable
Accessory Boards –
Communication
Acc-5E, Macro & I/O Interface, 300-
603437-10x
Acc-54E, USB/Ethernet TCP/IP
Communication, 300-603467-10x
Acc-55E, (UNET) Universal Field
Bus Adapter Net
work Card,
300-603485-10x
UMAC Backplane-Mountable
Accessory Boards –
Miscellaneous
Acc-28E, 2/4 Channel
16-Bit A/D Converter,
300-603404-10x
Acc-36E, 16-Channel 12-Bit A/D
Converter,
300-603483-10x
Acc-51E, x4096 Interpolator, 300-
603438-10x
Acc-53E, SSI,
300-603360-10x
Acc-56E, Extender Card, 300-
603401-10x
Acc-57E, Yaskawa or Mitsubishi
ABS, Encoder Unit, 300-603484-10x
Acc-58E, R/D Converter, 16 Bit, 300-
603482-10x
UBUS (UMAC’s Backplane
Boards)
Acc-U4, UBUS 4-Slot Backplane, 300-
603462-10x
Acc-U6, UBUS 6-Slot Backplane,
300-603403-10x
Acc-U8, UBUS 8-Slot Backplane,
300-603463-10x
Acc-U10, UBUS 10-Slot Backplane,
300-603464-10x
Acc-U12, UBUS 12-Slot Backplane,
300-603465-10x
Acc-U14, UBUS 14-Slot Backplane,
300-603466-10x
Acc-U16, UBUS 16-Slot Backplane,
300-603471-10x
Acc-U18, UBUS 18-Slot Backplane,
300-603491-10x
Amplifiers – Analog ±10VDC
Input (Brush Motors)
4-Axis Analog ± 10V Input Linear
Amplifier, 24VDC, 0.5/1A, 300-
603489-10x
4-Axis Analog ± 10V Input PWM
Amplifier, 48VDC, 2/4A, 300-
603443-10x
4-Axis Analog ± 10V Input PWM
Amplifier, 70VDC, 8/12A, 300-
603486-10x
Backplane, Double Analog Amplifier,
300-603470-10x
Backplane, Single Analog Amplifier,
300-603490-10x
Amplifiers – Digital PWM
Input (brushless)
2-Axis Digital PWM Amplifier,
360VDC, 4/8A, 400-603391-10x
2-Axis Digital PWM/Macro
Amplifier, 360VDC, 8/16A, 400-
603392-10x
Single Axis Digital PWM/ Macro
Amplifier, 360VDC, 8/16A, 401-
603391-10x
Single-Axis Digital PWM Amplifier,
360VDC, 8/16A, 401-603492-10x
Power Supply for 3U Digital PWM
Amplifiers,
400-603428-10x
Backplane, Digital PWM, 300-
603435-10x
Power Supplies – DC Input
Acc-F, 3U DC to DC Converter, 10A,
30F-603216-OPT
Power Supplies – AC Input
Acc-E, 3U AC Power Supply, 8A,
30E-603269-OPT
Acc-E1, 3U AC Power Supply, 14A,
31E-603269-OPT
Acc-E2, AC Power Supply, 20A,
32E-603468-OPT
UMAC Chassis Assemblies
(Rack)
3U Rack, 10-1/2 Slot (42T) 542-
602932-10x
3U Rack, 15-3/4 Slot (63T) 563-
602932-10x
3U Rack, 21 Slot (84T)
584-602932-10x
3U Rack, Variable Width per Customer
Requirements (custom design),
500-602932-10x
