PMAC PCI Lite Hardware Reference Manual
Connector Pinouts
4
5
CONNECTOR PINOUTS
J1: Display Port Connector
J1 JDISP (14-Pin Connector)
Front View
Pin # Symbol Function Description Notes
1 VDD Output +5V power Power supply out
2 VSS Common PMAC common
3 RS Output Read strobe TTL signal out
4 VEE Output Contrast adjust Vee 0 to +5Vdc *
5 E Output Display enable High is enable
6 R/W Output Read or write TTL signal out
7 DB1 Output Display Data 1
8 DB0 Output Display Data 0
9 DB3 Output Display Data 3
10 DB2 Output Display Data 2
11 DB5 Output Display Data 5
12 DB4 Output Display Data 4
13 DB7 Output Display Data 7
14 DB6 Output Display Data 6
* Controlled by potentiometer R1.
The JDISP connector is used to drive the 2-line x 24-character (Acc-12), 2 x 40 (Acc-12A) LCD, or the 2 x 40
vacuum fluorescent (Acc-12C) display unit. The
DISPLAY command may be used to send messages and values
to the display.
See:
Program Commands: DISPLAY
Accessories: Acc-12, 12A, 12C, Acc-16D
Memory Map: Y:$0780 - $07D1
