LEON-G100/G200 - System Integration Manual
GSM.G1-HW-09002-F3 Preliminary System description
Page 69 of 101
1.14 Approvals
1.14.1 Compliance with FCC and IC Rules and Regulations
LEON-G100/G200 modules are approved by the following regulatory bodies:
European Conformance CE mark: EC identification number 0682
R&TTED (Radio and Telecommunications Terminal Equipment Directive)
PTCRB (PCS Type Certification Review Board)
GCF (Global Certification Forum), partial compliance
AT&T network compatibility
CMIIT (China Ministry of Information Industry); SRRC (State Radio Regulation Center); Approval Code:
LEON-G100: CMIIT ID: 2010CJ0053
LEON-G200: CMIIT ID: 2010CJ0054
FCC (Federal Communications Commission) Identifier:
LEON-G100: XPYLEONG100
LEON-G200: XPYLEONG200
GOST-R, Hygienic, DoC
Radiofrequency radiation exposure Information: this equipment complies with FCC radiation
exposure limits prescribed for an uncontrolled environment. This equipment should be installed
and operated with a minimum distance of 20 cm between the radiator and your body. This
transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
IC (Industry Canada) Certification Number:
LEON-G100: 8595A-LEONG100
LEON-G200: 8595A-LEONG200
Manufacturers of mobile or fixed devices incorporating LEON-G100 / LEON-G200 modules are
authorized to use the FCC Grants and Industry Canada Certificates of the LEON-G100 / LEON-
G200 modules for their own final products according to the conditions referenced in the
certificates.
The FCC Label shall in the above case be visible from the outside, or the host device shall bear a
second label stating:
"Contains FCC ID: XPYLEONG100" resp. "Contains FCC ID XPYLEONG200".
IMPORTANT: Manufacturers of portable applications incorporating LEON-G100 / LEON-G200
modules are required to have their final product certified and apply for their own FCC Grant
and Industry Canada Certificate related to the specific portable device. This is mandatory to
meet the SAR requirements for portable devices.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
ICASA (Independent Communications Authority of South Africa)
