Table 157. System Conguration
Parameter Description
Serial Port 1—Serial Port 4 Select the option from the drop-down list. This option determines
how the built-in serial port operates. It avoids resource conicts
between devices by disabling or remapping the address of the port.
Integrated NIC From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the OS.
• Force Disabled—The internal LAN is o and not visible to the
OS.
• Enabled—The internal LAN is enabled.
• Enabled w/PXE—The internal LAN is enabled—with Preboot
Execution Environment (PXE) boot.
Integrated NIC 2 From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the OS.
• Force Disabled—The internal LAN is o and not visible to the
OS.
• Enabled—The internal LAN is enabled.
• Enabled w/PXE—The internal LAN is enabled—with Preboot
Execution Environment (PXE) boot.
SMART Reporting Select the check box to control the reporting of hard drive errors
for integrated drivers during system startup.
Enable UEFI Network Stack Select the check box to install or make available the UEFI
Networking protocols, allowing pre-OS and early OS networking
features to use any enabled NICs. This may be used without
switching on the PXE.
Watchdog Timer Support Select the check box to enable the watchdog timer feature.
Audio Select the check box to enable the integrated audio controller and
clear the Audio check box to completely disable audio controller,
including microphone.
Microphone Select the check box to enable the microphone.
WLAN Region Code Select the WLAN Region code from the drop-down list.
Table 158. USB Conguration
Parameter Description
Top Port 1– Top Port 4 If USB Port is enabled, the devices attached to this port are
enabled and available for OS and if the USB Port is disabled, the OS
cannot see any device attached to this port.
Bottom Port 1—Bottom Port 2 If USB Port is enabled, the devices attached to this port are
enabled and available for OS and if the USB Port is disabled, the OS
cannot see any device attached to this port.
CANBus/WWAN/Bluetooth/Bottom USB Port 3 and 4 If USB Port is enabled, the devices attached to this port are
enabled and available for OS and if the USB Port is disabled, the OS
cannot see any device attached to this port.
Enable USB Boot Support Select the check box to allow the system to boot any type of USB
Mass Storage Devices—HDD, memory key, oppy. USB-aware OS
