Network
Use this page to customize the network congurations like radio state, and manage wireless proles for the Embedded PC—Windows
devices.
Table 143. Network
Parameter Description
Radio State Select the check box to change the wireless radio state.
Windows Wireless Proles From the drop-down list, select your preferred windows wireless
proles. Only Windows wireless proles uploaded to File Repository
are listed.
Other
Use this page to specify more customizations like Windows/rmware auto-update for the Embedded PC—Windows devices.
Table 144. Other settings
Parameter Description
Enable Windows Auto Update Select the check box to enable the Windows automatic update
feature.
BIOS Embedded BOX PC 3000 settings
Use this section to dene BIOS settings such as Wake-On-LAN, auto-on, admin password, and so on.
Table 145. General
Parameter Description
Device Notes Enter the device notes such as property ownership tag.
Table 146. System Conguration
Parameter Description
COM1—COM3 Select the option from the drop-down list. This option determines
how the built-in port operates. It avoids resource conicts between
devices by disabling or remapping the address of the port.
Integrated NIC From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the OS.
• Force Disabled—The internal LAN is o and not visible to the
OS.
• Enabled—The internal LAN is enabled.
• Enabled w/PXE—The internal LAN is enabled—with Preboot
Execution Environment (PXE) boot.
NOTE: The device may lose connectivity with WMS, if you
disable both integrated NIC and integrated NIC 2.
Integrated NIC 2 From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
60 Managing group and congs
