Parameter Description
• Do not reboot.
Edge Gateway 3002 BIOS settings
Use this page to dene Edge Gateway 3002 BIOS settings such as Wake-On-LAN, Auto-On, and Admin Password.
Table 117. General
Parameter Description
Device Notes Enter the device notes such as property ownership tag.
Table 118. System Conguration
Parameter Description
Integrated NIC From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the OS.
• Force Disabled—The internal LAN is disabled and not visible to
the OS even if it has an IP address.
• Enabled—The internal LAN is enabled.
• Enabled w/PXE—The internal LAN is enabled—with Preboot
Execution Environment (PXE) boot.
Integrated NIC2 From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the OS.
• Force Disabled—The internal LAN is disabled and not visible to
the OS even if it has an IP address.
• Enabled—The internal LAN is enabled.
Enable UEFI Network Stack Select this check box to install or make available the UEFI
Networking protocols, allowing pre-OS and early OS networking
features to use any enabled NICs. This may be used without
switching on the PXE.
Watchdog Timer Support Select this check box to enable the Watchdog Timer feature.
Table 119. USB Conguration
Parameter Description
Enable USB 3.0 Ports Select this check box to enable the device attached to this port.
The device is also made available to the OS. If USB port is disabled,
OS cannot see any device attached to this port.
Enable USB Port 1 Select this check box to enable the device attached to this port.
The device is also made available to the OS. If USB port is disabled,
OS cannot see any device attached to this port.
Enable USB Port 2 Select this check box to enable the device attached to this port.
The device is also made available to the OS. If USB port is disabled,
OS cannot see any device attached to this port.
Enable USB Boot Support Select this check box to allow the system to boot any type of USB
Mass Storage Devices—HDD, memory key, oppy. USB-aware OS
52 Managing group and congs
