Parameter Description
WLAN Region Code From the drop-down list, select the WLAN region code.
Table 97. USB Conguration
Parameter Description
Enable USB 3.0 Ports Select this check box to enable the device attached to this port.
The device is also made available to the OS. If USB port is disabled,
OS cannot see any device attached to this port.
Enable Top USB Port 1 Select this check box to enable the device attached to this port.
The device is also made available to the OS. If USB port is disabled,
OS cannot see any device attached to this port.
Enable Top USB Port 2 Select this check box to enable the device attached to this port.
The device is also made available to the OS. If USB port is disabled,
OS cannot see any device attached to this port.
Enable Bottom USB Port 3 Select this check box to enable the device attached to this port.
The device is also made available to the OS. If USB port is disabled,
OS cannot see any device attached to this port.
Enable USB Boot Support Select this check box to allow the system to boot any type of USB
Mass Storage Devices—HDD, memory key, oppy. USB-aware OS
always sees USB Mass Storage devices irrespective of this setting,
provided the port is enabled.
Table 98. Wireless
Parameter Description
Enable WWAN Select this check box to enable Wireless Wide Area Network
(WWAN).
Enable WLAN Select this check box to enable Wireless Local Area Network
(WLAN).
Enable Bluetooth Select this check box to enable Bluetooth.
Enable CANBus Select this check box to enable CAN Bus.
Table 99. Security
Parameter Description
Admin Setup Lockout Select this check box to prevent users from entering Setup when
the Admin password is set.
Chassis Intrusion Chassis Intrusion is a utility that the BIOS can use to tell you that
someone has opened the case. From the drop-down list, you can
select any of the following options:
• Disable—Disable chassis intrusion feature.
• Enable—Report intrusions during POST.
• On-Silent—Enable intrusion detection but does not display any
detected intrusion.
UEFI Capsule Firmware Update Select this check box to control allowing the BIOS updates through
UEFI capsule update packages by the system. Disabling this option
blocks the BIOS updates from services such as Microsoft Windows
Update and Linux Vendor Firmware Service (LVFS).
Managing group and congs 47
