Parameter Description
Watchdog Timer Support Select the check box to enable the Watchdog Timer feature.
Table 80. USB Conguration
Parameter Description
Enable USB 3.0 Ports Select the check box to enable the device attached to this port.
The device is also made available to the operating system. If USB
port is disabled, operating system cannot recognise any device
attached to this port.
Enable Top USB Port 1 Select the check box to enable the device attached to this port.
The device is also made available to the operating system. If USB
port is disabled, operating system cannot recognise any device
attached to this port.
Enable Top USB Port 2 Select the check box to enable the device attached to this port.
The device is also made available to the operating system. If USB
port is disabled, operating system cannot recognise any device
attached to this port.
Enable Boot Support Select the check box to allow the system to boot any type of USB
Mass Storage Devices—HDD, memory key, oppy. USB-aware
operating system always recognizes the USB Mass Storage devices
irrespective of this setting if the port is enabled.
Table 81. Wireless
Parameter Description
Enable WWAN Select the check box to enable Wireless Wide Area Network
(WWAN).
Enable WLAN Select the check box to enable Wireless Local Area Network
(WLAN).
Enable Bluetooth Select the check box to enable Bluetooth.
Enable CANBus Select the check box to enable CAN Bus.
Table 82. Security
Parameter Description
Admin Setup Lockout Select the check box to prevent users from entering Setup when
the Admin password is set.
Chassis Intrusion Chassis Intrusion is a utility that the BIOS can use to tell your
someone has opened the case. From the drop-down list, you can
select any of the following options:
• Disable—Disable chassis intrusion feature.
• Enable—Report intrusions during POST.
• On-Silent—Enable intrusion detection but does not display any
detected intrusion.
UEFI Capsule Firmware Update Select the check box to allow system to update BIOS UEFI capsule
update packages by the system. Disabling this option blocks the
BIOS updates from services such as Microsoft Windows Update
and Linux Vendor Firmware Service (LVFS).
Managing group and congs 41
