Table 76. Maintenance settings
Parameter Description
BIOS Recovery—from Hard Drive Select this option to enable the user to recover from certain
corrupted BIOS conditions from a recovery le on the user primary
hard drive or an external USB key.
Table 77. Reboot Schedule
Parameter Description
Reboot Option Some BIOS settings require system reboot. When Reboot later is
selected, devices reboot when the current time matches the set
time. From the drop-down list, select any of the following options:
• Reboot immediately
• Reboot later
• Do not reboot.
Edge Gateway 3003 BIOS settings
Use this page to dene Edge Gateway 3003 BIOS settings.
Table 78. General
Parameter Description
Device Notes Enter the device notes such as property ownership tag.
Table 79. System Conguration
Parameter Description
Integrated NIC From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the
operating system.
• Force Disabled—The internal LAN is o and not visible to the
operating system even if it has an IP address.
• Enabled—The internal LAN is enabled.
• Enabled w/PXE—The internal LAN is enabled—with Preboot
Execution Environment (PXE) boot.
Integrated NIC 2 From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the
operating system.
• Force Disabled—The internal LAN is o and not visible to the
operating system even if it has an IP address.
• Enabled—The internal LAN is enabled.
Enable UEFI Network Stack Select the check box to install or make available the UEFI
Networking protocols, allowing pre-operating system and early
operating system networking features to use any enabled NICs.
This may be used without switching on PXE.
40 Managing group and congs
