Parameter Description
Extend BIOS POST Time From the drop-down list, select an option to create an extra
preboot delay which allows the user to see POST status messages.
The available options are:
• 0 seconds
• 5 seconds
• 10 seconds
Table 65. Maintenance settings
Parameter Description
BIOS Recovery—from Hard Drive Select the check box to enable the user to recover from certain
corrupted BIOS conditions from a recovery le on the user primary
hard drive or an external USB key.
Table 66. Reboot Schedule
Parameter Description
Reboot Option Some BIOS settings require system reboot. When Reboot later is
selected, devices reboot when the current time matches the set
time. From the drop-down list, select any of the following options:
• Reboot immediately
• Reboot later
• Do not reboot.
Edge Gateway 3002 BIOS settings
Use this page to dene Edge Gateway 3002 BIOS settings.
Table 67. General
Parameter Description
Device Notes Enter the device notes such as property ownership tag.
Table 68. System Conguration
Parameter Description
Integrated NIC From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the
operating system.
• Force Disabled—The internal LAN is o and not visible to the
operating system even if it has an IP address.
• Enabled—The internal LAN is enabled.
• Enabled w/PXE—The internal LAN is enabled—with Preboot
Execution Environment (PXE) boot.
Integrated NIC 2 From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
Managing group and congs 37
