Administrator Guide

Parameter Description
Enable Boot Support Select the check box to allow the system to boot any type of USB
Mass Storage Devices—HDD, memory key, oppy. USB-aware
operating system always recognizes the USB Mass Storage devices
irrespective of this setting if the port is enabled.
Table 32. Wireless
Parameter Description
Enable WWAN Select the check box to enable Wireless Wide Area Network
(WWAN).
Enable WLAN Select the check box to enable Wireless Local Area Network
(WLAN).
Table 33. Security
Parameter Description
Admin Setup Lockout Select the check box to prevent users from entering a setup when
the administrator password is set.
Chassis Intrusion Chassis Intrusion is a utility that the BIOS can use to tell you if
someone has opened the case. From the drop-down list, you can
select any of the following options:
• Disable—Disable chassis intrusion feature.
• Enable—Report intrusions during POST.
• On-Silent—Enable intrusion detection but does not display any
detected intrusion.
UEFI Capsule Firmware Update Select the check box to allow system to update BIOS UEFI capsule
update packages by the system. Disabling this option blocks the
BIOS updates from services such as Microsoft Windows Update
and Linux Vendor Firmware Service (LVFS).
Table 34. BIOS Admin Password
Parameter Description
Enable Admin Password Select this check box to enable the BIOS administrator password.
Table 35. Power Management settings
Parameter Description
Wake On LAN From the drop-down list, select an option to allow the computer to
power up from the o state when triggered by a special LAN signal
or from the hibernate state when triggered by a special wireless
LAN signal.
Table 36. Auto On settings
Parameter Description
Auto On From the drop-down list, set the time of day when you want the
system to turn on automatically.
28 Managing group and congs
