Edge Gateway 3002 BIOS settings
Use this page to dene Edge Gateway 3002 BIOS settings.
Table 29. General
Parameter Description
Device Notes Enter the device notes such as property ownership tag.
Table 30. System Conguration
Parameter Description
Integrated NIC From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the
operating system.
• Force Disabled—The internal LAN is o and not visible to the
operating system even if it has an IP address.
• Enabled—The internal LAN is enabled.
• Enabled w/PXE—The internal LAN is enabled—with Preboot
Execution Environment (PXE) boot.
Integrated NIC 2 From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the
operating system.
• Force Disabled—The internal LAN is o and not visible to the
operating system even if it has an IP address.
• Enabled—The internal LAN is enabled.
Enable UEFI Network Stack Select the check box to install or make available the UEFI
Networking protocols, allowing pre-operating system and early
operating system networking features to use any enabled NICs.
This may be used without switching on the PXE.
Watchdog Timer Support Select the check box to enable the Watchdog Timer feature.
Table 31. USB Conguration
Parameter Description
Enable USB 3.0 Ports Select the check box to enable the device attached to this port.
The device is also made available to the operating system. If USB
port is disabled, operating system cannot recognise any device
attached to this port.
Enable Top USB Port 1 Select the check box to enable the device attached to this port.
The device is also made available to the operating system. If USB
port is disabled, operating system cannot recognise any device
attached to this port.
Enable Top USB Port 2 Select the check box to enable the device attached to this port.
The device is also made available to the operating system. If USB
port is disabled, operating system cannot recognise any device
attached to this port.
