Parameter Description
City Species the city where your device is located.
Zip Code Species the zip code of the city where your device is located.
Country Species the country where your device is located.
Edge Gateway 5000 BIOS settings
Use this page to dene Edge Gateway 5000 BIOS settings.
Table 6. General settings
Parameter Description
Device Notes Enter the device notes such as property ownership tag.
Table 7. System conguration
Parameter Description
Integrated NIC From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the
operating system—only if it does not have an IP.
• Force Disabled—The internal LAN is disabled and not visible to
the operating system—even if it has an IP address.
• Enabled—The internal LAN is enabled.
• Enabled w/PXE—The internal LAN is enabled—with Preboot
Execution Environment (PXE) boot.
NOTE: The EDM connectivity is lost, if you disable both
integrated NIC and integrated NIC 2.
Integrated NIC2 From the drop-down list, select an option to control the on-board
LAN controller. The available options are:
• Disabled—The internal LAN is o and not visible to the
operating system—only if it does not have an IP address.
• Force Disabled—The internal LAN is disabled and not visible to
the operating system even if it has an IP address.
• Enabled—The internal LAN is enabled.
SMART Reporting Select the check box to control the reporting of hard drive errors
for integrated drivers during system startup.
Serial Port 1 RS232 Select the check box to determine how the built-in serial port
operates. It avoids resource conicts between the devices by
disabling or remapping the address of the port. This port is at 2D0h
with IRQ 7.
Serial Port 2 RS422 Select the check box to determine how the built-in serial port
operates. It avoids resource conicts between the devices by
disabling or remapping the address of the port. This port is at 3E0h
with IRQ 10.
Serial Port 3 RS485 Select the check box to determine how the built-in serial port
operates. It avoids resource conicts between the devices by
disabling or remapping the address of the port. This port is at 2E0h
with IRQ 11.
20 Managing group and congs
