The module provides the following power interfaces:
 48V DC via Power-over-Ethernet (POE)
 12V DC power supply
2.1.1.3 Indicator LEDs
There are 5 bicolor (power, ENET and WLAN) LEDs which operate as follows:
Table 1- AP-134 Indicator LEDs
Label Function Action Status
PWR AP power / ready status Off No power to AP
Red Initial power-up condition
Flashing – Green Device booting, not ready
On – Green Device ready
ENET0
ENET1
Ethernet Network Link
Status / Activity
Off Ethernet link unavailable
On – Amber 10/100Mbs Ethernet link
negotiated
On – Green 1000Mbps Ethernet link
negotiated
Flashing Ethernet link activity
11b/g/n 2.4GHz Radio Status Off 2.4GHz radio disabled
On – Amber 2.4GHz radio enabled in non-HT
WLAN mode
On – Green 2.4GHz radio enabled in HT
WLAN mode
Flashing – Green 2.4GHz Air monitor
11a/n 5GHz Radio Status Off 5GHz radio disabled
On – Amber 5GHz radio enabled in non-HT
WLAN mode
On – Green 5GHz radio enabled in HT WLAN
mode
Flashing – Green 5GHz Air monitor
2.2 AP-135
This section introduces the Aruba AP-135 Wireless Access Point (AP) with FIPS 140-2 Level 2 validation.
It describes the purpose of the AP, its physical attributes, and its interfaces.
