Table 2- AP-135 Indicator LEDs
Label Function Action Status
PWR AP power / ready status Off No power to AP
Red Initial power-up condition
Flashing – Green Device booting, not ready
On – Green Device ready
ENET0
ENET1
Ethernet Network Link
Status / Activity
Off Ethernet link unavailable
On – Amber 10/100Mbs Ethernet link
negotiated
On – Green 1000Mbps Ethernet link
negotiated
Flashing Ethernet link activity
11b/g/n 2.4GHz Radio Status Off 2.4GHz radio disabled
On – Amber 2.4GHz radio enabled in non-HT
WLAN mode
On – Green 2.4GHz radio enabled in HT
WLAN mode
Flashing – Green 2.4GHz Air monitor
11a/n 5GHz Radio Status Off 5GHz radio disabled
On – Amber 5GHz radio enabled in non-HT
WLAN mode
On – Green 5GHz radio enabled in HT WLAN
mode
Flashing – Green 5GHz Air monitor
