Parameter Description
Security
Level
l When Reauth interval is configured on an SSID performing only L3
authentication (captive portal authentication)—When reauthentication
succeeds, a pre-authentication role is assigned to the client that is in a
post-authentication role. Due to this, the clients are required to go
through captive portal to regain access.
Blacklisting
To enable blacklisting of the clients with a specific number of authentication
failures, select Enabled from the Blacklisting drop-down list and specify a
value for Max authentication failures. The users who fail to authenticate
the number of times specified in Max authentication failures are
dynamically blacklisted.
Enterprise,
Personal, and
Open security
levels.
Accounting Select any of the following options:
l To enable accounting, select Use authentication servers from the
Accounting drop-down list. On enabling the accounting function, W-IAPs
post accounting information to the RADIUS server at the specified
Accounting interval.
l To use a separate server for accounting, select Use separate servers.
The accounting server is distinguished from the authentication server
specified for the SSIDprofile.
l To disable the accounting function, select Disabled.
Enterprise,
Personal, and
Open security
levels.
Authentication
survivability
To enable authentication survivability, set Authentication survivability to
Enabled. Specify a value in hours for Cache timeout (global) to set the
duration after which the authenticated credentials in the cache must expire.
When the cache expires, the clients are required to authenticate again. You
can specify a value within a range of 1–99 hours and the default value is 24
hours.
NOTE: The authentication survivability feature requires ClearPass Policy
Manager 6.0.2 or later, and is available only when the New server option is
selected. On setting this parameter to Enabled, Instant authenticates the
previously connected clients using EAP-PEAP authentication even when
connectivity to ClearPass Policy Manager is temporarily lost. The
Authentication survivability feature is not applicable when a RADIUS server
is configured as an internal server.
Enterprise
security level
MAC
authentication
To enable MAC-address-based authentication for Personal and Open
security levels, set MAC authentication to Enabled.
For Enterprise security level, the following options are available:
l Perform MAC authentication before 802.1X—Select this check box to
use 802.1X authentication only when the MAC authentication is
successful.
l MAC authentication fail-thru—On selecting this check box, the 802.1X
authentication is attempted when the MAC authentication fails.
NOTE: If Enterprise Security level is chosen, the server used for mac
Enterprise,
Personal, and
Open security
levels.
Table 23: Configuration Parameters for WLANSecurity Settings in an Employee or Voice Network
