75 | IPv6 Support Dell Networking W-Series Instant 6.5.1.0-4.3.1.0 | User Guide
When the IP mode is set to v4-prefer mode, the W-IAP derives a link local IPv6 address and attempts to acquire
a routable IPv6 address by monitoring Router Advertisements (RA) packets. W-IAP assigns itself to both
Stateless address autoconfiguration (SLAAC) and DHCPv6 client address. W-IAPs also support IPv6 DNS server
addresses and use these for DNS resolution.
In the CLI:
To enable IPv4 mode or dual stack mode:
(Instant AP)(config)# ip-mode {v4-only|v4-prefer}
(Instant AP)(config)# end
(Instant AP)(config)# commit apply
Configuring IPv6 Address for a W-IAP
You can enable the IPv6 mode on the W-IAP and also configure a VCIPv6 address using the Instant UI or the
CLI:
In the Instant UI:
To enable IPv6 and configure VC IPv6 address:
1. Go to the System link, directly above the Search bar in the Instant UI.
2. Under General, select the Allow IPv6 Management check box.
3. Enter the IPaddress in the Virtual Controller IPv6 address text box.
4. Click OK.
In the CLI:
To configure an IPv6 address for a W-IAP:
(Instant AP)(config)# virtual-controller-ipv6 <ipv6 address>
(Instant AP)(config)# end
(Instant AP)# commit apply
The VC IPv6 address can be configured only after enabling the v4-prefer mode in the Instant CLI.
RADIUS over IPv6
With the address mode set to v4-prefer, the W-IAP supports an IPv6 IP address for the RADIUS server. The
authentication server configuration can also include the NAS IPv6 address (that defaults to the routable IPv6
address when not configured).
To configure an IPv6 address for the RADIUS server:
(Instant AP)(config)# wlan auth-server radiusIPv6
(Instant AP)(Auth Server "radiusIPv6")# ip <host>
(Instant AP)(Auth Server "radiusIPv6")# nas-ip <ip_ipv6>
(Instant AP)(Auth Server "radiusIPv6")# end
(Instant AP)# commit apply
SNMP Over IPv6
In this release, you can configure a community string to authenticate messages sent between the VC and the
SNMP agent, where the IPv6 address will be used as the VCaddress.For more information on configuring
SNMPparameters, see Configuring SNMP on page 362.
To view the SNMPconfiguration:
(Instant AP)# show running-config|include snmp
snmp-server community e96a5ff136b5f481b6b55af75d7735c16ee1f61ba082d7ee
snmp-server host 2001:470:20::121 version 2c aruba-string inform
