Icon
number
Name Description
1 Signal Displays the signal strength of the client. Signal strength is measured in decibels.
Depending on the signal strength of the client, the color of the lines on the Signal icon
changes in the following order:
l Green—Signal strength is more than 20 dB.
l Orange—Signal strength is between 15 dB and 20 dB.
l Red—Signal strength is less than 15 dB.
To view the signal graph for a client, click the signal icon next to the client in the Signal
column.
2 Speed Displays the data transfer speed of the client. Depending on the data transfer speed of
the client, the color of the Speed icon changes in the following order:
l Green—Data transfer speed is more than 50% of the maximum speed supported by
the client.
l Orange—Data transfer speed is between 25% and 50% of the maximum speed
supported by the client.
l Red—Data transfer speed is less than 25% of the maximum speed supported by the
client.
To view the data transfer speed graph of a client, click the speed icon corresponding to
the client name in the Speed column.
3 Utilization Displays the radio utilization rate of the W-IAPs. Depending on the percentage of
utilization, the color of the lines on the Utilization icon changes in the following order:
l Green—Utilization is less than 50%.
l Orange—Utilization is between 50% and 75%.
l Red—Utilization is more than 75%.
To view the utilization graph of a W-IAP, click the Utilization icon next to the W-IAP in the
Utilization column.
Table 11: RF Dashboard Icons
