l Centralized, L3
For more information on configuring DHCP profiles, see Configuring DHCP Scopes on page 207.
A Centralized, L2 or Distributed, L2 VLAN or subnet cannot be used to serve W-IAPs in a hierarchical mode of
deployment. Ensure that the physical IP of the W-IAPs connecting to the master W-IAP in hierarchical mode
of deployment is not on a VLAN or subnet that is in Centralized, L2 or Distributed, L2 mode of operation. For
information on hierarchical mode of deployment, see Understanding Hierarchical Deployment on page 111.
Configuring an SSID or Wired Port
For a client to connect to the IAP-VPNnetwork, an SSID or wired port profile on a W-IAP must be configured
with appropriate IAP-VPN mode of operation. The VLAN configuration in an SSID or wired port profile
determines whether an SSID or wired port is configured for the IAP-VPN operations.
To configure an SSID or wired port for a specific IAP-VPNmode, the VLAN ID defined in the SSID or wired port
profile must match the VLAN ID defined in the DHCP profile configuration. If the VLAN assignment for an SSID
or wired port profile is set to VC assigned, custom, or a static VLAN ID that does not match the VLAN ID
configured in the DHCP profiles, the IAP-VPN operations are affected. For example, if a local DHCP profile is
configured with a VLAN ID of 200, the VLAN configuration on the SSID must be set to a static VLAN ID 200.
Ensure that the VLAN assignment for an SSID or wired port profile is not set to default as the VPN tunnel is
not supported on the default VLAN.
For information on how to configure an SSID or wired port profile, see Wireless Network Profiles on page 77
and Configuring a Wired Profile on page 104, respectively.
Enabling Dynamic RADIUS Proxy
The RADIUS server can be deployed at different locations and VLANs. In most cases, a centralized RADIUSor
local server is used to authenticate users. However, some user networks can use a local RADIUS server for
employee authentication and a centralized RADIUS-based captive portal server for guest authentication. To
ensure that the RADIUS traffic is routed to the required RADIUS server, the dynamic RADIUSproxy feature
must be enabled. When enabled, dynamic RADIUSproxy ensures that all the RADIUS traffic is sourced from
the VC IP or inner IP of the W-IAP IPsec tunnel depending on the RADIUS server IP and routing profile.
Ensure that a static VC IP is configured before enabling dynamic RADIUS proxy in order to tunnel the RADIUS
traffic to the central RADIUS server in the datacenter.
For information on enabling dynamic RADIUS proxy, see Configuring Dynamic RADIUSProxy Parameters on
page 158.
Configuring Enterprise Domains
By default, all the DNS requests from a client are forwarded to the client's DNS server. In a typical W-IAP
deployment without VPN configuration, client DNS requests are resolved by the DNS server of clients. For the
IAP-VPN scenario, the enterprise domain settings on the W-IAP are used to determine how client DNS requests
are routed. For information on how to configure enterprise domains, see Configuring Enterprise Domains on
page 192.
Configuring a Controller for IAP-VPN Operations
Dell Networking W-Series controllers provide an ability to terminate the IPsec and GRE VPNtunnels from the
W-IAP and provide corporate connectivity to the branch network.
