Chapter 19
IAP-VPN Deployment
This section provides the following information:
l Understanding IAP-VPN Architecture on page 238
l Configuring W-IAP and Controller for IAP-VPN Operations on page 241
Understanding IAP-VPN Architecture
The IAP-VPN architecture includes the following two components:
l W-IAPs at branch sites
l Controller at the datacenter
The master W-IAP at the branch site acts as the VPN endpoint and the controller at the datacenter acts as the
VPN concentrator. When a W-IAP is set up for VPN, it forms an IPsec tunnel to the controller to secure sensitive
corporate data. IPsec authentication and authorization between the controller and the W-IAPs are based on
the RAP whitelist configured on the controller.
Only the master W-IAP in a W-IAP cluster forms the VPN tunnel.
From the controller perspective, the master W-IAPs that form the VPN tunnel are considered as VPN clients.
The controller terminates VPNtunnels and routes or switches the VPN traffic. The W-IAP cluster creates an
IPsec or GRE VPNtunnel from the VC to a Mobility Controller in a branch office. The controller only acts as an
IPsec or GRE VPN endpoint and it does not configure the W-IAP.
IAP-VPN Scalability Limits
The controller scalability in IAP-VPN architecture depends on factors such as IPsec tunnel limit, Branch ID limit,
and datapath route table limit. The following table provides the IAP-VPN scalability information for various
controller platforms:
Platforms Branches Routes L3 Mode Users NATUsers Total L2 Users
W-3200 1000 1000
N/A N/A
64,000
W-3400 2000 2000 64,000
W-3600 8000 8000 64,000
W-6000M3 8000 8000 64,000
W-7210 8000 8000 64,000
W-7220 16,000 16,000 128,000
W-7240 32,000 32,000 128,000
Table 50: IAP-VPN Scalability
