Dell Networking W-Series Instant 6.5.1.0-4.3.1.0 | User Guide Configuring Time-Based Services | 217
Chapter 16
Configuring Time-Based Services
This chapter describes time range profiles and the procedure for configuring time-based services. It includes
the following topics:
l Time Range Profiles on page 217
l Configuring a Time Range Profile on page 217
l Applying a Time Range Profile to a WLAN SSID on page 218
l Verifying the Configuration on page 219
Time Range Profiles
Starting from Instant 6.4.3.4-4.2.1.0, W-IAPs allow you to enable or disable an SSID for users at a particular
time of the day. You can now create a time range profile and assign it to a WLANSSID, so that user access to
the Internet or network is restricted during a specific time period.
W-IAPs support the configuration of both absolute and periodic time range profiles. You can configure an
absolute time range profile to execute during a specific timeframe or create a periodic profile to execute at
regular intervals based on the periodicity specified in the configuration.
The following configuration conditions apply to the time-based services:
l Time-based services require an active NTP server connection. W-IAPs use the default NTP server for time
synchronization. However, the administrators can also configure an NTP server on the W-IAP. To verify the
time synchronization between the NTP server and the W-IAP, execute the show time-range command and
check if the time on the NTP server is in synchronization with the local time. For more information on NTP
server configuration, see NTPServer.
l For a time range profile configured to enable the SSIDon the W-IAP:
n When the timer starts, if the current time is greater than the start time and lesser than the end time, the
SSIDwill be brought UP. If the SSIDis already UP, then there is no effect on the SSID.
n When the timer ends, if the current time is greater than the end time, the SSIDis brought DOWN. If the
SSIDis already DOWN, then there is no effect on the SSID.
l For a time range profile configured to disable the SSIDon the W-IAP:
n When the timer starts, if the current time is greater than the start time and lesser than the end time, the
SSIDwill be brought DOWN. If the SSIDis already DOWN, then there is no effect on the SSID.
n When the timer ends, if the current time is greater than the end time, the SSIDis brought UP. If the
SSIDis already UP, then there is no effect on the SSID.
Configuring a Time Range Profile
You can create time range profiles using the Instant UI or the CLI.
In the Instant UI
To create a time range profile:
1. Navigate to System > Show advanced options > Time Based Services .
2. Click New under Time Range Profiles. The New Profile window for creating time range profiles is
displayed.
3. Configure the parameters listed in the following table:
