Concept Guide

RADIUS VSA Attributes
The user role can be derived from Dell Vendor-Specific Attributes (VSA) for RADIUS server authentication. The
role derived from a Dell VSA takes precedence over roles defined by other methods.
MAC-Address Attribute
The first three octets in a MAC address are known as Organizationally Unique Identifier (OUI), and are
purchased from the Institute of Electrical and Electronics Engineers, Incorporated (IEEE) Registration Authority.
This identifier uniquely identifies a vendor, manufacturer, or other organization (referred to by the IEEE as the
“assignee”) globally and effectively reserves a block of each possible type of derivative identifier (such as MAC
addresses) for the exclusive use of the assignee.
W-IAPs use the OUI part of a MAC address to identify the device manufacturer and can be configured to assign
a desired role for users who have completed 802.1X authentication and MAC authentication. The user role can
be derived from the user attributes after a client associates with an W-IAP. You can configure rules to assign a
user role to clients that match a MAC-address-based criteria. For example, you can assign a voice role to any
client with a MAC address starting with a0:a1:a2.
Roles Based on Client Authentication
The user role can be the default user role configured for an authentication method, such as 802.1X
authentication. For each authentication method, you can configure a default role for the clients who are
successfully authenticated using that method.
DHCP Option and DHCP Fingerprinting
The DHCP fingerprinting allows you to identify the operating system of a device by looking at the options in
the DHCP frame. Based on the operating system type, a role can be assigned to the device.
For example, to create a role assignment rule with the DHCP option, select equals from the Operator drop-
down list and enter 370103060F77FC in the String text box. Since 370103060F77FC is the fingerprint for
Apple iOS devices such as iPad and iPhone, W-IAP assigns Apple iOS devices to the role that you choose.
Device DHCP Option DHCP Fingerprint
Apple iOS Option 55 370103060F77FC
Android Option 60 3C64686370636420342E302E3135
Blackberry Option 60 3C426C61636B4265727279
Windows 7/Vista Desktop Option 55 37010f03062c2e2f1f2179f92b
Windows XP (SP3, Home,
Professional)
Option 55 37010f03062c2e2f1f21f92b
Windows Mobile Option 60 3c4d6963726f736f66742057696e646f777320434500
Windows 7 Phone Option 55 370103060f2c2e2f
Apple Mac OS X Option 55 370103060f775ffc2c2e2f
Table 41: Validated DHCP Fingerprint
Creating a Role Derivation Rule
You can configure rules for determining the role that is assigned for each authenticated client.
