181 | Roles and Policies Dell Networking W-Series Instant 6.5.1.0-4.3.1.0 | User Guide
Service
Category
Description
Blacklist
Select the Blacklist check box to blacklist the client when this rule is triggered. The
blacklisting lasts for the duration specified as Auth failure blacklist time on the
Blacklisting tab of the Security window. For more information, see Blacklisting Clients on
page 172.
Classify media
Select the Classify media check box to prioritize video and voice traffic. When enabled, a
packet inspection is performed on all non-NAT traffic and the traffic is marked as follows:
l Video: Priority 5 (Critical)
l Voice: Priority 6 (Internetwork Control)
Disable scanning
Select Disable scanning check box to disable ARM scanning when this rule is triggered.
The selection of Disable scanning applies only if ARM scanning is enabled. For more
information, see Configuring Radio Settings on page 256.
DSCP tag
Select the DSCP tag check box to specify a DSCP value to prioritize traffic when this rule is
triggered. Specify a value within the range of 0–63. To assign a higher priority, specify a
higher value.
802.1p priority
Select the 802.1p priority check box to specify an 802.1p priority. Specify a value between
0 and 7. To assign a higher priority, specify a higher value.
Table 39: Access Rule Configuration Parameters
6. Click OK and then click Finish.
In the CLI
To configure access rules:
(Instant AP)(config)# wlan access-rule <access-rule-name>
(Instant AP)(Access Rule <Name>)#rule <dest> <mask> <match/invert> {<protocol> <start-port>
<end-port> {permit|deny|src-nat [vlan <vlan_id>|tunnel]|dst-nat{<IP-address> <port>|<port>}}
[<option1....option9>]
(Instant AP)(Access Rule <Name>)# end
(Instant AP)# commit apply
Example
(Instant AP)(config)# wlan access-rule employee
(Instant AP)(Access Rule "employee")# rule 10.17.88.59 255.255.255.255 match 6 4343 4343 log
classify-media
(Instant AP)(Access Rule "employee")# rule 192.0.2.8 255.255.255.255 invert 6 110 110 permit
(Instant AP)(Access Rule "employee")# rule 192.0.2.2 255.255.255.0 192.0.2.7 255.255.255.0
match tcp 21 21 deny
(Instant AP)(Access Rule "employee")# rule 192.0.2.2 255.255.255.0 192.0.2.7 255.255.255.0
match udp 21 21 deny
(Instant AP)(Access Rule "employee")# rule 192.0.2.2 255.255.255.0 match 6 631 631 permit
(Instant AP)(Access Rule "employee")# rule 192.0.2.8 255.255.255.255 invert 6 21 21 deny
(Instant AP)(Access Rule "employee")# rule 192.0.2.1 255.255.255.0 invert 17 67 69 deny
(Instant AP)(Access Rule "employee")# end
(Instant AP)# commit apply
