2. On the Access tab, move the slider to Role-based access control by using the scroll bar.
3. Select a role or create a new one if required.
4. Click New to add a new rule. The New Rule window is displayed.
5. In the New Rule window, specify the following parameters. The following figures show the parameters for
captive portal role configuration:
Figure 32 Captive Portal Rule for Internal Splash Page Type
Figure 33 Captive Portal Rule for External Splash Page Type
Parameter Description
Rule type
Select Captive Portal from the RuleType drop-down list.
Splash Page
Type
Select any of the following attributes:
l Select Internal to configure a rule for internal captive portal authentication.
l Select External to configure a rule for external captive portal authentication.
Internal
If Internal is selected as splash page type, perform the following steps:
l Under Splash Page Visuals, use the editor to specify display text and colors
for the initial page that would be displayed to users connecting to the
network. The initial page asks for user credentials or email, depending on the
splash page type configured.
l To change the color of the splash page, click the Splash page rectangle and
select the required color from the Background Color palette.
Table 30: Captive Portal Rule Configuration Parameters
