W-IAPModel (Reg

Domain)

W-IAP###-

(US only)

W-IAP###-

JP (Japan

only)

W-IAP###-

(Rest of the

World

except

US/JP)

W-IAP274/275 Yes Yes Yes

W-IAP228 Yes Yes Yes

W-IAP224/225 Yes Yes

Yes

W-IAP214/215 Yes Yes Yes

W-IAP205H Yes Yes Yes

W-IAP204/205 Yes Yes Yes

W-IAP155/155P

Yes Yes No

W-IAP114/115 Yes Yes

Yes

W-IAP108/109 Yes Yes No

W-IAP103

Yes Yes Yes

Table 4: Supported W-IAP Variants

For information on regulatory domains and the list of countries supported by the W-IAP###-RW type, see the

Specifying Country Code section in Logging in to the Instant UI on page 19

Instant UI

The Instant User Interface (UI) provides a standard web-based interface that allows you to configure and

monitor a Wi-Fi network. Instant is accessible through a standard web browser from a remote management

console or workstation and can be launched using the following browsers:

l Microsoft Internet Explorer 11 or earlier

l Apple Safari 6.0 or later

l Google Chrome 23.0.1271.95 or later

l Mozilla Firefox 17.0 or later

If the Instant UI is launched through an unsupported browser, a warning message is displayed along with a list

of recommended browsers. However, the users are allowed to log in using the Continue login link on the

To view the Instant UI, ensure that JavaScript is enabled on the web browser.

The Instant UI logs out automatically if the window is inactive for 15 minutes.

Dell Networking W-Series Instant 6.5.1.0-4.3.1.0 | User Guide About Instant | 13
