Deleting a Wired Profile
To delete a wired profile:
1. Click the Wired link under More on the Instant main window. The Wired window is displayed.
2. In the Wired window, select the wired profile to delete.
3. Click Delete. The wired profile is deleted.
Link Aggregation Control Protocol
The W-IAP220 Series access points and W-IAP270 Series support the IEEE 802.11ac standard for high-
performance WLAN. To support maximum traffic, port aggregation is required as it increases throughput and
enhances reliability. To support port aggregation, Instant supports Link Aggregation Control Protocol (LACP)
based on the IEEE 802.3ad standard. The 802.3ad standard for Ethernet aggregation uses LACP as a method
to manage link configuration and balance traffic among aggregated ports.
LACP provides a standardized means for exchanging information with partner systems to form a dynamic link
aggregation group. The LACP feature is automatically enabled during W-IAP boots and it dynamically detects
the W-IAP if connected to a partner system with LACP capability, by checking if there is any LACP Protocol Data
Unit (PDU) received on either Ethernet 0 or Ethernet 1 port.
If a switch in the cluster has the LACP capability, you can combine Ethernet 0 or Ethernet 1 interfaces into the
link aggregation group to form a single logical interface (port-channel). Port-channels can be used to provide
additional bandwidth or link redundancy between two devices. W-IAP supports link aggregation using either
standard port-channel (configuration based) or Link Aggregation Control Protocol (protocol signaling based).
You can deploy W-IAP228 Series or W-IAP27x Series access points with LACP configuration to benefit from the
higher (greater than 1 Gbps) aggregate throughput capabilities of the two radios.
The LACP feature is supported only on W-IAP228 Series and W-IAP27x Series access points.
Verifying LACP Configuration on the W-IAP
There is no configuration required on the W-IAPfor enabling LACP support. However, you can view the status
of LACP on W-IAPs by using the following command:
(Instant AP)# show lacp status
AP LACP Status
--------------
Link Status LACP Rate Num Ports Actor Key Partner Key Partner MAC
----------- --------- --------- --------- ----------- -----------
Up slow 2 17 1 70:81:05:11:3e:80
Slave Interface Status
----------------------
Slave I/f Name Permanent MAC Addr Link Status Member of LAG Link Fail Count
-------------- ------------------ ----------- ------------- ---------------
eth0 6c:f3:7f:c6:76:6e Up Yes 0
eth1 6c:f3:7f:c6:76:6f Up Yes 0
Traffic Sent on Enet Ports
--------------------------
Radio Num Enet 0 Tx Count Enet 1 Tx Count
--------- --------------- ---------------
0 0 0
1 0 0
non-wifi 2 17
