452 | show l3-mobility Dell Networking W-Series Instant 6.4.3.1-4.2.0.0 | CLI Reference Guide
Parameter Description
IP
Indicates the IP address of the roaming client.
Dir
Indicates if the client has roamed in or out of the mobility subnet.
Peer IP
Displays the peer IP address, if any peer clients are configured.
Home Vlan
Displays the VLAN ID associated with the home subnet.
VAP Vlan
Displays the VLAN ID associated with the Virtual AP.
Tunnel ID
Indicates the tunnel interface used for routing packets.
Old AP IP
Indicates the IP address of the W-IAP from which the client has roamed.
FAP IP
Indicates the IP address of the W-IAP in the foreign subnet.
HAP IP
Indicates the IP address of the W-IAP in the home subnet, to which the client is
currently connected.
VC IP
Indicates the IP address of the Virtual Controller.
Additional Info
Displays additional information if any.
show l3-mobility status
The following example shows the output of the show l3-mobility status command:
Roaming Client Table
--------------------
Client MAC Home Vlan VAP Vlan Tunnel ID Status Virtual Controller IP Peer IP Old AP IP Device
Name
---------- --------- -------- --------- ------ --------------------- ------- --------- -------
----
Tunnel Table
------------
Peer IP Local Tunnel ID Remote Tunnel ID Use Count Type
------- --------------- ---------------- --------- ----
Virtual Controller Table
------------------------
Virtual Controller IP Type HAP IP Local Tunnel ID Remote Tunnel ID
--------------------- ---- ------ --------------- ----------------
192.0.1.0 C - - -
The output of this command provides the following information:
Parameter Description
Roaming Client
Table
Displays details such as client MAC address, Home AP and Virtual APVLAN,
Tunnel ID, roaming status, Virtual Controller IP address, peer IP address, old IP
address, and the name of the device.
Tunnel Table
Displays details such as peer IP address, local tunnel ID. remote tunnel ID, tunnel
count, and the type of tunnel used for routing packets.
