450 | show l3-mobility Dell Networking W-Series Instant 6.4.3.1-4.2.0.0 | CLI Reference Guide
Column Description
Value
Indicates if a flag is enabled.
Virtual Controller IP
Displays the Virtual Controller IP address. The Virtual Controller IP
configuration for each W-IAP allows the clients to roam seamlessly among all
the W-IAPs.
Subnet
Indicates the IP address for the mobility domain.
Netmask
Displays the subnet mask configuration details.
VLAN
Displays the VLAN ID configured for the mobility domain.
Virtual Controller
Displays the Virtual Controller configuration associated with the mobility
domain.
show l3-mobility datapath
The following example shows the output of show l3-mobility datapath command:
L3 Mobility Datapath Home Table
-------------------------------
Client Index Client MAC Home Vlan Destinaton Device Index
------------ ---------- --------- -----------------------
L3 Mobility Datapath Foreign Table
----------------------------------
Client Index Client MAC Home Vlan VAP Vlan Destinaton Device Index HAP IP Virtual Controller
IP Packets Forwarded
-------------- -----------------
L3 Mobility Datapath Tunnel Table
---------------------------------
Tunnel Device Remote Protocol Dest IP Clients Idle Time Rx Packets Tx Packets Rx Mcasts Tx
Mcasts ARP Proxy Pkts Tx Jumbo MTU Rx HB Tx HB MTU Reqs MTU Resps HB Mismatch IP Mismatch Type
Vlan Translations
------------- --------------- ------- ------- --------- ---------- ---------- --------- ------
--- -------------- -------- --- ----- ----- -------- --------- ----------- ----------- ---- --
---------------
The output of this command provides the following information:
Parameter Description
L3 Mobility
Datapath Home
Table
Displays details such as client index, client MAC address, VLAN, destination device
associated with the L3 mobility home subnet.
L3 Mobility
Datapath Foreign
Table
Displays details such as client index, client MAC address, VLAN, Destination
device, home AP IP address, Virtual Controller IP address and packet details
associated with the L3 mobility foreign subnet.
L3 Mobility
Datapath Tunnel
table
Displays the following details about L3 mobility tunnel:
l Tunnel - Indicates the tunnel interface.
l Device - Displays the device ID.
l Remote Protocol - Indicates the remote protocol used by the roaming clients.
