370 | show clients Dell Networking W-Series Instant 6.4.3.1-4.2.0.0 | CLI Reference Guide
Column Description
Name
Displays the name of the client
IP address
Displays the IP address of the client.
MAC address
Displays the MAC address of the client.
OS
Indicates the OS running on the client system.
Network
Indicates the SSID and network to which the client is connected.
Access Point
Indicates the IP address of the Access Point to which the client is connected.
Channel
Indicates the channel assigned to the client.
Type
Indicates the type of the Wi-Fi client device.
Role
Indicates the role assigned to the client.
Signal
Indicates the current signal strength of the client, as detected by the W-IAP.
Speed(Mbps)
Indicates the current speed at which data is transmitted. When the client is
associated with a W-IAP, it constantly negotiates the speed of data transfer. A
value of 0 means that the W-IAP has not received any packets from the client
for some time.
show clients <diff>
The show clients <diff> command displays the change in the clients table data that occurred during the
specified interval. For example, if the value specified for <diff> parameter is 10 seconds, the client table
displays the changes such as signal strength or speed that occurred since the last 10 seconds.
show accounting <mac>
The show accounting <mac> command displays the accounting information such as status and session ID
for a specific client MAC address.
show checksum <mac>
The following output is displayed for the show checksum <mac> command:
Mac Address:08:ed:b9:e1:51:7d
Basic info
----------
mac
---
08 ed b9 e1 51 7d
bssid
d8 c7 c8 3d 3d 52
ap_ip
0a 11 58 ba
name
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00
essid
73 72 6f 79 2d 73 6f 6d 65 74 68 69 6e 67 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00
