show ap mesh neighbors
show ap mesh neighbors
Description
This command shows all mesh neighbors for an AP.
Example
The following example shows the output of show ap mesh neighbors command:
Neighbor list
-------------
MAC Portal Channel Age Hops Cost Relation Flags RSSI Rate Tx/Rx A-Req A-Resp A-Fail HT-Details
Cluster ID
--- ------ ------- --- ---- ---- -------- ----- ---- ---------- ----- ------ ------ ----------
----------
6c:f3:7f:a5:df:90 Yes 157 23 0 5.00 N 23s HLK 33 - 0 0 0 HT-20MHzsgi-3ss
78042e34005c8b372de0472df0727ef
6c:f3:7f:a5:df:30 Yes 153 0 0 5.00 N 3d:18h:16m:4s HLK 13 - 0 0 0 HT-20MHzsgi-3ss
b8e356bcb60d4ce984d9a7077a43936
d8:c7:c8:3d:3b:10 Yes 161 15 0 5.00 N 15s HLK 50 - 0 0 0 HT-20MHzsgi-3ss
78042e34005c8b372de0472df0727ef
Total count: 3, Children: 0
Relation: P = Parent; C = Child; N = Neighbor; B = Blacklisted-neighbor
Flags: R = Recovery-mode; S = Sub-threshold link; D = Reselection backoff; F = Auth-failure; H
= High Throughput; L = Legacy allowed
K = Connected; U = Upgrading; G = Descendant-upgrading; Z = Config pending; Y = Assoc-
resp/Auth pending
a = SAE Accepted; b = SAE Blacklisted-neighbour; e = SAE Enabled; u = portal-unreachable; o =
opensystem
The output of this command includes the following information:
Parameter Description
MAC
MAC address of the mesh node.
Portal
By default, this column displays the BSSID of the mesh point. If you include the
optional names parameter, this column will display AP names, if available. The
AP names will include [p] (parent), or [c] (child) suffixes to indicate the role of
the mesh BSSID.
Channel
Number of a radio channel used by the AP.
Age
Number of seconds elapsed since the AP heard from the neighbor.
Hops
Indicates the number of hops it takes traffic from the mesh node to get to the
mesh portal. The mesh portal advertises a hop count of 0, while all other mesh
nodes advertise a cumulative count based on the parent mesh node.
Cost
A relative measure of the quality of the path from the AP to the Virtual
Controller. A lower number indicates a better quality path, where a higher
number indicates a less favorable path (e.g, a path which may be longer or
more congested than a path with a lower value.) For a mesh point, the path cost
is the sum of the (parent path cost) + (the parent node cost) + (the link cost).
