302 | show ap debug dot1x-statistics Dell Networking W-Series Instant 6.4.3.1-4.2.0.0 | CLI Reference Guide
show ap debug dot1x-statistics
show ap debug dot1x-statistics
Description
This command displays the aggregate 802.11X debug statistics for a W-IAP.
Usage Guidelines
Use this command to view information about the 802.11x authentication.
Example
The following output is displayed for the show ap debug dot1x-statistics command:
802.1X Statistics
-----------------
Mac Name AP Auth-Succs Auth-Fails Auth-Tmout Re-Auths
---------- ------ ---- ---------- -------- --------- ------- -------
08:ed:b9:e1:51:7d d8:c7:c8:3d:42:12 0 0 0 0
Total: 0 0 0 0
Supp-Naks UKeyRot MKeyRot ---------- -------- --------
0 0 0
0 0 0
802.1x Counters
WPA2
Message-1......................3
Message-2......................2
Message-3......................2
Message-4......................2
The output of this command includes the following parameters:
Parameter Description
Mac
Displays the MAC address of the authenticated client.
Name
Displays the name of the client device
AP
Displays the AP device details to which the client is connected.
Auth-Succs
Displays the number of times the client authenticated successfully.
Auth-Fails
Displays the number of times the client failed to authenticate.
Auth-Timeout
Displays if client authentication timeout details.
Reauths
Displays the reauthentication attempts if any.
Supp-Naks
Displays the number of supplementary NAKs.
UkeyRot
Displays the unicast key rotation details.
