show ap debug airwave
show ap debug airwave
Description
This command displays the list of W-AirWave servers configured on a W-IAP.
Usage Guidelines
Use this command to view the list of W-AirWave servers configured for a W-IAP.
Example
The following example shows the output of show ap airwave command:
Airwave Server List
-------------------
Domain/IP Address Type Mode Status
---------- ---- ---- ------
test.com Primary - Not connected
test1.com Backup - Not connected
The output of this command includes the following information:
Column Description
Domain/IP Address
Displays the IP address or domain name of the W-AirWave server.
Type
Displays the type of the W-AirWave server. For example, backup or primary
server.
Mode
Indicates the mode of W-AirWave operation.
NOTE: W-AirWave can be configured to operate in the Manage Read/Write or
Monitor-only+ Firmware Upgrades modes.
Status
Indicates the W-AirWave login status.
Command History
Version Description
Dell Networking W-Series Instant 6.3.1.1-4.0
The Domain name is added.
Dell Networking W-Series Instant 6.2.1.0-3.3
This command is introduced.
Command Information
W-IAP Platform Command Mode
All platforms
Privileged EXEC mode
