1628| show ipv4 user-table Dell Networking W-Series ArubaOS 6.5.x| Reference Guide
Parameter Description
web
Show data for devices using captive portal authentication.
bssid
Displays entries in the IPv4 user-table that are associated to the specified
BSSID.
debug
Displays entries in the IPv4 user-table that are in debug mode.
essid
Displays entries in the IPv4 user-table that are associated to the specified
ESSID. If the ESSID includes spaces, you must enclose it in quotation marks.
internal
Displays internal IPv4 users.
ip <A.B.C.D>
Displays IPv4 users that match the specified IPv4 IP address.
log
Displays the log information for the specified IPv4 client.
mac
Displays users with the specified MAC address.
mobile
Displays list of mobile users in the IPv4 user table. The following filters are
available for this parameter:
l bindings—list of users that have moved away from the current controller.
l rows—displays entries that match the specified row number.
l unique—displays unique entries in the IPv6 user-table.
l visitors—displays users that have associated with the current controller.
name
Displays IPv4 user table entries that match the specified name.
phy-type
Displays IPv4 user table entries that match a or b phy-type.
role
Displays IPv4 user table entries that match the specified role.
rows
Displays specific rows in the IPv4 user table. Enter the starting row number
and the number of rows to be displayed.
station
Displays the station table information for the IPv4 user table entries.
verbose
Displays the complete IPv4 user table with all details.
Example
This example displays a list of users.
(host) #show ipv4 user-table
Users
-----
IP MAC Name Role Age(d:h:m) Auth
VPN link AP name Roaming Essid/Bssid/Phy Profile
Forward mode Type Host Name
