Users Guide

Installing Oracle RAC 10g R2 Using ASM 33
f In the Generate stamps with this prefix field, keep the default settings
and click
Next.
g In the Stamp disks window, click Next .
h Click Finish to save your settings.
i Select the check boxes next to the available disks and click OK .
16 In the ASM Disk Groups window, click Create New .
17 In the Create Disk Group window, enter the information for the Flash
Recovery Area.
a In the Disk Group Name field, type a name for the new disk group.
For example, FLASH.
b In the Redundancy box, select External .
c Click Stamp Disks .
d In the Select disks window, select the disks that you plan to use for the
Flash Recovery Area. After you select the disks, the status is marked as
Candidate device .
e In the Generate stamps with this prefix field, type FLASH and
click
Next.
f In the Stamp disks window, click Next .
g Click Finish to save your settings.
h Select the check boxes next to the available disks and click OK .
The
ASM Disk Group window is displayed, indicating that the software is
creating the disk group. When the disk group creation is complete, the
FLASH disk group is displayed in the
Disk Group Name column.
18 In the Database File Locations window, select Use Oracle-Managed Files ,
Multiplex Redo Logs, and Control Files and click Next .
19 In the Recovery Configuration window:
a Select Specify Flash Recovery Area .
b Click Browse .
c Select the FLASH disk group that you created in step 17 and click OK .
d In the Flash Recovery Area Size text box type the total size of the
flash disk group that you created.
