Users Guide

24 Installing Oracle RAC 10g R2 Using ASM
5 In the Product Specification Prerequisite Checks window:
•
For Windows Server 2003 : Ensure that the installation program
completes all the checks successfully and then click
Next .
•
For Windows Server 2008 : The Product Specification Prerequisite
Check
fails for the OCFS and Orafence Driver’s Signature.
To continue with the installation, select the
Checking OCFS &
Orafence Driver's Signature
check box when the installation performs
the prerequisite checks. This changes the field label to
User Verified .
To resolve this issue, apply Oracle patch 7320726 immediately after
you complete the Oracle Clusterware installation and before you
install the database binaries. For more information on applying
Oracle
patch 7320726, see “Applying Oracle Patch 7320726 for Windows
Server 2008” on page 26.
6 In the Specify Cluster Configuration window, perform the following steps:
a Verify the public, private, and virtual host names for the primary node.
b If you want to change these values, click Edit , enter the required
values, and click
OK .
c Click Add .
d Enter the public, private, and virtual host names for the second node,
and click
OK .
7 Click Next .
The
Specify Network Interface Usage window is displayed, which displays a
list of cluster-wide network interfaces.
8 To change the Interface Type :
a Select the Interface Name and click Edit .
b Select one of the following options:
•
Public — to make the interface a public interface
•
Private — to make the interface a private interface
•
Do not use — for all other interfaces.
c Click OK .
9 Click Next .
